902-608
Ratcheted Crimper for
Non–insulated Terminals
DESCRIPTION: This AWG 8‑2 Crimper is ideal for electronics and electrical
installation purposes. Features high leverage handles and a compound action
mechanism. The accurate crimping mold and self‑locking / releasing mechanical
unit design ensures high crimping quality with repeated crimps. Made of high‑
quality carbon steel with black oxide finish for anti‑rust.
FEATURES:
• For non–insulated spade/ring terminals AWG 8, 6, 4, 2
• Accurate crimping mold
• Self–locking/releasing mechanical unit
• Overall length: 14"
CP-353
Ratcheted Crimper for
Non–insulated Terminals
DESCRIPTION: This heavy duty crimper is for crimping non‑insulated
terminals of AWG 12‑10, 8, 6, and 4. Features high leverage handles and a
compound action mechanism. The accurate crimping mold and self‑locking
/ releasing mechanical unit design ensures high crimping quality with
repeated crimps. Made of high‑quality carbon steel with black oxide finish
for anti‑rust.
FEATURES:
• For non–insulated terminals AWG 12–10, 8, 6, 4
• Self–locking–releasing mechanism unit design
• Overall length: 13"
300-107
Heavy Duty Crimping Tool – 8 AWG to 250 MCM
DESCRIPTION: The Indent Crimping Method can be done with an
easy‑to‑operate hand tool and eliminates the need to select/guess die
size. The Indent Crimper takes out the guesswork with non‑incremental
knob adjustment for crimp depth. The 250 MCM Indent Crimper is the
best crimping solution for Heavy Duty tinned terminals and is designed for
use with all battery and welding cable, building wiring and crimp terminal lugs.
The adjustment screw allows the user to quickly set the tool for a wide range of
terminal sizes. Solid steel construction ensures a long lifespan.
FEATURES:
• For terminating insulated and non–insulated cable lugs:
8, 6, 4, 2, 1/0, 2/0, 3/0, 250 MCM
• Two capacity plates – aluminum and copper
• Lightweight and easy to operate
• Overall length: 22.4"
