CRIMPING

902-498
Terminal Crimp Kit w/100–002

DESCRIPTION: 176 pcs Terminal Crimp Kit with all‑in‑one crimper/stripper. For use on
generic red, blue and yellow insulated and non‑insulated terminals. Wire Stripper: AWG
22‑20, 18, 16, 14, 12, 10. Bolt Cutter: 4‑40, 6‑32, 10‑24, 10‑32, 8‑32
SET INCLUDES:
• Includes Crimper #100–002
• Butt splice connector, insulated PVC, copper tubular
AWG 22–16, red x 30 pcs
AWG 16–14, blue x 20 pcs
AWG 12–10, yellow x 15 pcs
• Ring terminal, insulated PVC, brazed seam
AWG 22–16, #6 Stud size, red x 50 pcs
AWG 16–14, #8 Stud size, blue x 40 pcs
AWG 12–10, #10 Stud size, yellow x 20 pcs
• Plastic storage/carrying case

CP-151B
Ratcheted Crimper for
Non–insulated Terminals

DESCRIPTION: This ratcheted crimper crimps non‑insulated
terminals of AWG 22‑16, 16‑14, 12, 10. The dieless crimp
head means no dies to change out for different size terminals.

FEATURES:
• Crimping type: indent crimping
• Crimping range: AWG 10 – 1/0
• Overall length: 7"

CP-251B
Ratcheted Crimper for
Non–insulated Terminals

DESCRIPTION: This heavy duty mechanical crimper is for use on
Non‑Insulated Spade/Ring Terminals, ensures an gas‑tight crimp
and features a sleek, compact design for a comfortable grip and
easy storage. In addition, its energy‑saving ratcheted design makes
repeated crimps a breeze.
FEATURES:
• Non–insulated spade/ring terminals
• AWG 22–16/16–14/12–10/8/6
• Frame: S45C
• Die: AISI 4141
• HRC: 40º – 42º
• Non–slip TPR handle with eyelets for easy storage and carrying
• Overall length: 10"
