Internally adjusted externally adjusted
The internally adjusted line of crimp tools is designed for adjustments by The externally adjustable line of tools is designed to accept MS3191-
qualified personnel only. This tool features an adjustment knob located 4 and M22520/1 style turret head assemblies. Theses tools have a
inside the front cover plate of the tool. Once set by qualified personnel, micrometer style adjustment knob which allows them to be adjusted and PRODUCT LISTINGS
the tool is not adjustable by the assembly line operator, thus helping set to crimp depths ranging from .015 to .085 inches in increments of
to eliminate operator error. The tool operates with replaceable, single .001. The dial indicator on this style of tool has three sets of numbers.
position locators. When using these locators, the internally adjustable One set indicates crimp depth in thousandths of an inch. One set
tools can crimp a wire range of 8-30 AWG. The internally adjusted tools corresponds to the selector knob settings on the M22520/1-01 (615708)
can be adapted to accept the MS3191-4 and M22520/1 turrets by tool. The third set corresponds to the selector settings on the MS3191-4
ordering a 620754 turret adaptor assembly. (612179) tool. These multi-selector readings allow the tool to be used
easily with the data for crimp settings located on all Mil-Spec turrets.
Standard internally adjustable tool: 612871 In its turret-operated configuration these tools crimp contact sizes 12
Mini tip tool: part number 612768. through 26 and wire sizes 12 through 30 AWG.
4 indent style tool: part number 11221. Standard externally adjustable tool: 612141
4 indent style tool with 3 locators: part number 10967. This tool can be adapted for use with locators by ordering the 615161
slide strap adaptor assembly.
3212 (20 GA.) 3213 (16 GA.) 3214 (12 GA.)
A tool with a mini tip indenter is available under part number 615250.
locators for Ms applications
Contact size locator Part # Contacts accommodated (Ref.)
20 3212 MS 3190 MS 24254
16 3213 MS 3192 MS 3193 MS 24225 NAS 1662 NAS 1663 MS 18134
12 3214 MS 18136 M39029/4 M39020/5
20 11568-1 MS 17803 MS 17807
16 11568-1 MS 17804 MS 17808 M39029/34 M39029/35
22 612507 MS 27491-22, 22D, 22M MS 27492-22, 22D, 22M MS 27493-22, 22D, 22M MS 27494-22, 22D, 22M M39029/57 M39029/58
613264 M39029/56 MS 27490-22, 22D, 22M
20 7005626 M39029/56 M39029/57 M39029/58 MS 27490-20 MS27491-20 MS27492-20 MS27493-20 MS27494-20
16 7008289 M39029/58 MS 27493-16 MS 27494-16
7008300 M39020/56 M39029/57 MS 27490-16 MS 27491-16 MS 27492-16
12 7008290 M39029/56 M39029/57 M39029/58 MS 27490-12 MS 27491-12 MS 27492-12 MS 27493-12 MS 27494-12
25
