Pneumatic Crimp tool aPC708 (functional equivalent to M22520/1-01) PRODUCT LISTINGS

Ms #. astRo tool # usaGe/DesCRIPtIon nsn.
• Portable or bench-mounted
M22520/3-1 615716 Gage For /1-01 /2-01 5220-00-165-7604
• Cycle controlled ratchet
M22520/1-02 615709 Turret 5120-00-016-6382
M22520/1-03 615710 Turret 5120-00-016-6554
M22520/1-04 615711 Turret 5120-00-016-7582 8-step adjustable Manual feed
M22520/1-05 615712 Universal Positioner 5120-00-165-3911 Pneumatic Crimping tool aPC708
M22520/1-06 615713 Positioner 5120-00-016-7647 The aPC708, 8-Step Adjustable Manual Feed Pneumatic
M22520/1-07 615714 Positioner 5120-00-016-7651 Crimping Tool is a fast, versatile, pneumatically actuated
four indenter tool for crimping MS style or proprietary circular
M22520/1-08 615715 Turret 5120-00-016-7654
contacts. This tool accommodates all turret head assemblies
M22520/1-09 615821 Positioner 5120-00-132-5039 used with the M22520/1-01 crimping tool. The tool is capable
M22520/1-10 615822 Positioner 5120-00-132-5095 of accommodating contact sizes 12 to 26 and wire sizes 12 to
30 AWG.
M22520/1-11 616406 Positioner 5120-01-127-5231
M22520/1-12 616407 Turret 5120-01-036-9220 Astro manufactures the ATK6002 gaging kit with the gaging
pin assemblies for each selector setting. Contact the factory for
M22520/1-13 616408 Turret 5120-01-036-9221
price and availability.
M22520/1-14 616409 Turret 5120-01-036-9222
M22520/1-15 616410 Positioner 5120-01-036-9223 Tool can be either hand held or mounted on an optional bench
mount (P/N 11380). The tool can be actuated by the tool trigger
M22520/1-16 620172 Positioner 5120-01-075-8138
or a foot pedal assembly (P/N 11380-2). (The bench mount and
M22520/1-17 620537 Positioner foot pedal can be purchased together as P/N 11380-3). Using
these accessories leaves the operator’s hands free for inserting
and removing contacts and wire.
This tool operates on 80-120 P.S.I. Astro recommends a filtered,
regulated and lubricated air supply for optimal performance.
Astro offers the 11413 air regulator for this purpose.
