三坐标测量机步距规

水平使用

6882-600A

单位: mm
A
符合JB/T步距规国家
40
机械行业标准 30
用于检测机床工作台移动 10 20 10 10
精度, 校准三坐标测量机,
数显高度规, 高度尺, 卡尺
立卧两用
陶瓷量块 B

标准精度(符合JB/T步距规国家机械行业标准0级) (mm)
型号 规格 量块间隔 A B 内尺寸测量范围 外尺寸测量范围 高度测量范围
10, 30, 50, 70, 90, 110, 10, 30, 50, 70, 90, 110, 30, 50, 70, 90, 110, 130,
6882-300A* 0-300mm 10mm 310 350 130, 150, 170, 190, 210, 130, 150, 170, 190, 210, 150, 170, 190, 210, 230,
230, 250, 270, 290 230, 250, 270, 290, 310 250, 270, 290, 310, 330

10, 30, 50, 70, 90, 110, 10, 30, 50, 70, 90, 110, 30, 50, 70, 90, 110, 130,
6882-400A* 0-400mm 10mm 410 450 130, 150, 170, 190, 210, 130, 150, 170, 190, 210, 150, 170, 190, 210, 230,
230, 250, 270, 290, 310, 230, 250, 270, 290, 310, 250, 270, 290, 310, 330,
330, 350, 370, 390 330, 350, 370, 390, 410 350, 370, 390, 410, 430

10, 30, 50, 70, 90, 110, 10, 30, 50, 70, 90, 110, 30, 50, 70, 90, 110, 130,
130, 150, 170, 190, 210, 130, 150, 170, 190, 210, 150, 170, 190, 210, 230,
6882-500A* 0-500mm 10mm 510 550 230, 250, 270, 290, 310, 230, 250, 270, 290, 310, 250, 270, 290, 310, 330,
330, 350, 370, 390, 410, 330, 350, 370, 390, 410, 350, 370, 390, 410, 430,
430, 450, 470, 490 430, 450, 470, 490, 510 450, 470, 490, 510, 530

10, 30, 50, 70, 90, 110, 10, 30, 50, 70, 90, 110, 30, 50, 70, 90, 110, 130,
130, 150, 170, 190, 210, 130, 150, 170, 190, 210, 150, 170, 190, 210, 230, 28
6882-600A* 0-600mm 10mm 610 650 230, 250, 270, 290, 310, 230, 250, 270, 290, 310, 250, 270, 290, 310, 330,

330, 350, 370, 390, 410, 330, 350, 370, 390, 410, 350, 370, 390, 410, 430,
430, 450, 470, 490, 510, 430, 450, 470, 490, 510, 450, 470, 490, 510, 530,
530, 550, 570, 590 530, 550, 570, 590, 610 550, 570, 590, 610, 630

10, 30, 50, 70, 90, 110, 30, 50, 70, 90, 110, 130,
10, 30, 50, 70, 90, 110, 130, 150, 170, 190, 210, 150, 170, 190, 210, 230,
130, 150, 170, 190, 210,
230, 250, 270, 290, 310, 230, 250, 270, 290, 310, 250, 270, 290, 310, 330,
330, 350, 370, 390, 410, 330, 350, 370, 390, 410, 350, 370, 390, 410, 430,
430, 450, 470, 490, 510,
450, 470, 490, 510, 530,
6882-1000A* 0-1000mm 10mm 1010 1050 430, 450, 470, 490, 510, 530, 550, 570, 590, 610, 550, 570, 590, 610, 630,
530, 550, 570, 590, 610,
630, 650, 670, 690, 710, 650, 670, 690, 710, 730,
630, 650, 670, 690, 710, 730, 750, 770, 790, 810, 750, 770, 790, 810, 830,
730, 750, 770, 790, 810,
830, 850, 870, 890, 910, 830, 850, 870, 890, 910, 850, 870, 890, 910, 930,
930, 950, 970, 990 930, 950, 970, 990, 950, 970, 990, 1010,
1010 1030
待续
