三坐标测量机测针

德国制造

ISQ-01-2010-020STR
ISQ-02-2030-040ST
单位: mm
Ød1
Ø3 M2 Ød 单位: mm
L1 Ø3
L M2 M2
L
M2测针(不锈钢基座) (mm)
型号 Ød Ød1 L L1 测杆材质 测头材质
ISQ-01-2010-010STR 1 0.8 10 4
M2测针延长杆 (mm)
ISQ-01-2010-020LTR 1 0.8 20 7
型号 L 材质
ISQ-01-2010-020STR 1 0.8 20 13
ISQ-02-2030-005ST 5
ISQ-01-2010-028STR 1 0.8 27.5 20.5
ISQ-02-2030-010ST 10
ISQ-01-2015-020STR 1.5 1 20 13
ISQ-02-2030-020ST 20 不锈钢
ISQ-01-2015-030STR 1.5 1 30 23
ISQ-02-2030-030ST 30
ISQ-01-2020-020STR 2 1 20 13
ISQ-02-2030-040ST 40
ISQ-01-2020-030STR 2 1.5 30 23
ISQ-01-2020-040STR 2 1.5 40 33
ISQ-01-2025-020STR 2.5 1.5 20 13
碳化钨
ISQ-01-2025-030STR 2.5 2 30 23
单位: mm
ISQ-01-2025-040STR 2.5 2 40 33
红宝石 Ø3
ISQ-01-2030-020STR 3 1.5 20 13
M2 M2
ISQ-01-2030-030STR 3 2 30 23
L
ISQ-01-2030-040STR 3 2 40 33
ISQ-01-2030-050STR 3 2 50 43
ISQ-01-2040-022STR 4 2 22 15
ISQ-01-2040-030STR 4 2 30 23 M2测针延长杆 (mm)
ISQ-01-2040-040STR 4 2 40 33 型号 L 材质
ISQ-01-2040-050STR 4 2 50 43 ISQ-02-2035-030SCF 30
28 ISQ-01-2020-020SSR 2 1.5 20 13 ISQ-02-2035-040SCF 40
ISQ-01-2030-020SSR 3 1.5 20 13 不锈钢 ISQ-02-2035-050SCF 50 碳纤维
ISQ-01-2040-020SSR 4 1.5 20 13 ISQ-02-2035-060SCF 60
ISQ-01-2030-050SCE 3 2 50 43 陶瓷 ISQ-02-2035-070SCF 70

单位: mm
D
M2
单位: mm
4-M2 Ø4 M2 M3
8
5
L
M2
M2多路测针中心座 (mm) M2转接头 (mm)
型号 D 备注 材质 型号 L 材质
ISQ-03-2075-008ST 7.5 4路 ISQ-05-2040-005M3 5
不锈钢 不锈钢
ISQ-03-2070-008ST 7 5路 ISQ-05-2040-007M3 7
待续
