P. 597
接上页 公制细牙螺纹塞规
规格(mm) 型号(4139) * 规格(mm) 型号(4139) * 规格(mm) 型号(4139) *
公称直径 螺距 等级6H 等级6G 等级4H 公称直径 螺距 等级6H 等级6G 等级4H 公称直径 螺距 等级6H 等级6G 等级4H
1.5 -62R -62RG -62RH 1.5 -75R -75RG -75RH 2 -95T -95TG -95TH
2 -62T -62TG -62TH 2 -75T -75TG -75TH 3 -95V -95VG -95VH
M62 M75 M95
3 -62V -62VG -62VH 3 -75V -75VG -75VH 4 -95X -95XG -95XH
4 -62X -62XG -62XH 4 -75X -75XG -75XH 6 -95O -95OG -95OH
1.5 -64R -64RG -64RH 1.5 -76R -76RG -76RH 2 -100T -100TG -100TH
2 -64T -64TG -64TH 2 -76T -76TG -76TH 3 -100V -100VG -100VH
M64 M100
3 -64V -64VG -64VH M76 3 -76V -76VG -76VH 4 -100X -100XG -100XH
4 -64X -64XG -64XH 4 -76X -76XG -76XH 6 -100O -100OG -100OH
1.5 -65R -65RG -65RH 6 -76O -76OG -76OH 2 -105T -105TG -105TH
2 -65T -65TG -65TH M78 2 -78T -78TG -78TH 3 -105V -105VG -105VH
M65 M105
3 -65V -65VG -65VH 1.5 -80R -80RG -80RH 4 -105X -105XG -105XH
4 -65X -65XG -65XH 2 -80T -80TG -80TH 6 -105O -105OG -105OH
1.5 -68R -68RG -68RH M80 3 -80V -80VG -80VH 2 -110T -110TG -110TH
2 -68T -68TG -68TH 4 -80X -80XG -80XH 3 -110V -110VG -110VH
M68 M110
3 -68V -68VG -68VH 6 -80O -80OG -80OH 4 -110X -110XG -110XH
4 -68X -68XG -68XH M82 2 -82T -82TG -82TH 6 -110O -110OG -110OH
1.5 -70R -70RG -70RH 2 -85T -85TG -85TH 2 -115T -115TG -115TH
2 -70T -70TG -70TH 3 -85V -85VG -85VH 3 -115V -115VG -115VH
M85 M115
M70 3 -70V -70VG -70VH 4 -85X -85XG -85XH 4 -115X -115XG -115XH
4 -70X -70XG -70XH 6 -85O -85OG -85OH 6 -115O -115OG -115OH
6 -70O -70OG -70OH 2 -90T -90TG -90TH 2 -120T -120TG -120TH
1.5 -72R -72RG -72RH 3 -90V -90VG -90VH 3 -120V -120VG -120VH
M90 M120
2 -72T -72TG -72TH 4 -90X -90XG -90XH 4 -120X -120XG -120XH
M72 3 -72V -72VG -72VH 6 -90O -90OG -90OH 6 -120O -120OG -120OH
4 -72X -72XG -72XH
6 -72O -72OG -72OH
14
注意: 寿命有限, 公制螺纹环规
可使⽤约2000次
* 型号说明举例:
等级6g
公称直径 螺距
GO(通)
4120-16 4120-16N
M2 0.4 -2
型号为4120-2
符合GB/T普通螺纹量规国家标准
带生产厂检验证书
待续
