3200/2BI 3202/1P 3057/2
Chain breaker, press and riveting tool Master link clip pliers for motorcycle Variator and clutch drive holder tool
for motorbike chain with ring wrench

› The pliers enable assembly and disassembly › material: premium plus carbon steel
of the connecting link clip on the motorcycle’s › surface "nish: chrome plated to standard ISO

chain. 1456:2009
› material: premium plus carbon steel
› material: premium &ex plus carbon steel › drop forged, entirely hardened and tempered Advantages:

› surface "nish: chrome plated to standard ISO › cutting edges induction hardened › comes with 3 di!erent lengths of accessories

1456:2009 › head polished that cover several types of drives
› ergonomic heavy duty double component › surface "nish: chrome plated to standard ISO

handle 1456:2009 Usage:
› Dimension of box: 321 x 198 x 54 › handles plastic dipped › for scooters PIAGGIO, GILERA 50-125ccm; water-
and air-cooled
Usage: Advantages: › has a triple function
› for DID chains with graduation 520, 525, 530 › Specially designed groove enables easy › it is used as a block for the gear on the starter
and 532
when untightening the front part of the drive
› for Regina chains with graduation 520, 525, 530 positioning and prevents the pliers from › accessories for holding the pot on the back part

slipping o! the chain’s pin.
› for RK chains with graduation 520, 525, 530 and
532 › The jaw is shortened for easier assembly or of the drive for untightening the nut
› compatible with most motorcycle drive chains disassembly of the clip. › wrench for untightening the inside nut of the
back part of the drive
Disassembling the chain:
› a robust set for disassembling a chain without
any prior grinding of the pin
› select the appropriate pin (diameter Ø3, Ø3,5 B
or Ø5 mm) and lower guide (Ø4 Ø5 or Ø6 mm) C
corresponding to the pin diameter on the chain L
› insert the pin into the tool, then position the A
tool on the chain link and rotate the tool until
the chain pin falls out
SKU L B A SKU TA A2 MB C S1 S2 L
Assembling the chain: 628803 180 27 10 221 623187 22 80 32,5 34 38 262 319
› assemble the chain according to the
manufacturer's instructions
› select an appropriate set of pressing adaptors
depending on the size of the plates (guide
widths to 13.5 mm or 16 mm)
› position the set into the tool. Place the tool on
the connecting chain link and press the link by
rotating the riveting tool using the handle until
the plates and the chain are tightly connected
› after the chain link and the plates have been
successfully aligned, install the chain pin
› You can choose from 3 types of riveting pins
(type A, B or C)
› place the riveting set into the tool and rotate
the handle to cause a deformation of the head
of the pin, so the diameter is between 5.5 to 5.8
mm as recommend the chain manufacturer's
instructions

SKU B H L
623220 40 115 270 2490
