3050/2BI 3051/2BI
Clutch and gear wheel holding tools Rotor and sprocket holding tools

› material: premium plus carbon steel
› surface "nish: chrome plated to standard ISO

1456:2009
› ergonomic heavy duty double component handle
Advantages:
› Its wedge-shaped gripping shanks provide grip
between teeth while preventing them from being
damaged.
› The tool also includes a screw, which enables

the tool to be "xed in a certain position and,

consequently, a "rm grip. › material: premium plus carbon steel

› surface "nish: chrome plated to standard ISO 1456:2009
Usage: › ergonomic heavy duty double component handle
› The tool is designed for holding the clutch, gears
and the cam shaft when tightening gears in Advantages:
the range up to 130mm during assembly and › Due to its universal structure, it allows holding holes with a diameter of 5 or 9 mm and at a distance between
disassembly. 20 to 180 mm.

› all types of motorbikes › The tool also has a screw that enables "xing of the tool at the actual distance between holes on the magnet
or the sprocket.
Usage:
› The tool is designed for holding the magnet and the sprocket during assembly or disassembly.
› all types of motorbikes

SKU D D C B A L SKU D D D1 D2 L B
620261 40 130 48 6 412 390 637 620262 20 180 4.4 7.2 340 32 604

3055/4A
Flywheel puller with external thread

› material: premium plus carbon steel

› surface "nish: blacken to standard DIN 50938
› treads M10, M14, M16, M18, M24 are right hand, M27 are left hand
Advantages:

› The tool has 6 di!erent sizes of external thread, thus enabling coverage of the majority of motor types

that have a &ywheel with an internal thread.
› allows &ywheel removal without pulling motor from hull

› On each axis, there is an attachment for an open-end wrench that makes the removal of the magnet
easier.
Usage:
› for removal of the &ywheel with internal thread

SKU M M1 M2 M3 M4 M5 S1 S2 S3 A B
620278 M10 x 1 M14 x 1,5 M16 x 1,5 M18 x 1,5 M24 x 1 M27 x 1 24 14 11 168 160 531

276 MOTORCYCLE TOOLS
