380 385H 514/1BI
Wire stripper Cable stripper with hook knife Multifunctional electrician`s pliers

› material: polyamide
Advantages:
› no damage of the inner conductors can occur › material: premium plus carbon steel
due to in"nitely variable adjustment of the › drop forged, entirely hardened and tempered

cutting depth › cutting edges induction hardened
› material: polyamide
› the swivel blade automatically turns from › head polished

circular to longitudinal cut › surface "nish: chrome plated according to ISO
Advantages: 1456:2009
› adjustable length stop of 5-12 mm Usage: › heavy duty double - component handles
› easily accessible built - in side cutter for max. › accurate, fast and safe stripping of all common
2mm
round cables of 4-28 mm² Advantages:

› 7 di!erent functions
Usage: › multi-toothed jaw
› fully insulated automatic wire stripper for all › ergonomically shaped handle
common standard and solid conductors of 0, › extra strong grip
2-6mm²
› Extra strong grip - the design and shape of
the handles give the hand more leverage
L during use, enabling more stability and safer
transmission of force.
SKU SKU L › high durability
610925 0.2 - 6 117 610930 4 - 28 170 91 › Multi-toothed jaw prevents slipping and
enables a better grip of cables, wires etc.
385G 478/1BI Usage:
› The ground part of the jaw is intended for
Cable stripper with straight knife Wire stripping pliers gripping objects with sensitive surfaces.
› The pliers can be used for crimping insulated
spade terminals.
› Stripping o! insulations from Ø 2.2 mm to Ø

3.0 mm.
› Stripping o! insulations from Ø 3.5 mm to Ø

4.0 mm.
› Cutting wires from Ø 2.2 mm to Ø 4.0 mm.
› Crimping cable terminals up to Ø 4.0 mm.
› material: polyamide
Advantages:
› no damage of the inner conductors can occur › material: premium plus carbon steel
due to in"nitely variable adjustment of the › drop forged, entirely hardened and tempered

cutting depth › cutting edges induction hardened
› the swivel blade automatically turns from › head polished
circular to longitudinal cut › surface "nish: chrome plated to standard ISO

1456:2009
Usage: › heavy duty double - component handles
› accurate, fast and safe stripping of all common
round cables of 4-28 mm² Advantages:
› spring for reopening
› stripping capacity: up to max 0.6 - 10mm²

SKU L B D A C
612782 160 16 2.5 9 49 141
L cutting capacity (10N=1kg) max 1600 N/mm" ∅ max 650 N/mm" ∅
L
SKU
612782 160 1,6 2,0
SKU L
610931 4 - 28 170 92

SKU L B A C
607882 160 0.6 - 10 18 9 40 178

STRIPPING 115
