Punchdown

PT Punchdown Tool
The primary tool for all telecom and datacom installers working with 110, 66, Krone, and BIX style cross connects. This professional tool
will provide precise, repeatable, and reliable terminations that will help ensure installations pass certification and your peace-of-mind.

Features
• Terminate and cut Cat3/5/5e/6 cables
• Spring loaded for fast, low effort wire seating
and termination
• Bayonet style (twist and lock) blade retention socket
is compatible with industry standard tools and blades
• 110, 66, 630, Krone, and BIX style
interchangeable blades
• Built-in hook – feeds or removes wire
• Built-in spudger – for screwdriver, IDC insert tool,
or to clean debris
• Adjustable Hi-Lo force impact settings are
precisely controlled to meet the industry
standard 8762D spec 13306C
• Large blade storage compartment

Part # Description
13300C Punchdown Tool, handle only
™
13305C Punchdown Tool, w/NEVERDull 66 Blade
™
13306C Punchdown Tool, w/NEVERDull 110 Blade
™
13307C Punchdown Tool, w/NEVERDull 66 & 110 Blades
™
13309C Punchdown Tool, w/NEVERDull 66/110 Combo Blade

Non-Impact Tool with PRO Punchdown Kit

110 EZ-Data Cut Blade ® Keeps your tools readily accessible
This economical non-impact tool includes the patented and organized so you’re always ready
110 EZ-Data Cut Blade for a new level of performance. It to perform those datacom jobs.
features a precision ground, replaceable cutting knife with This tool pouch kit will quickly
a beveled cutting edge for faster, cleaner terminations. become part of your daily gear.
Kit includes a black, Fine Tip Sharpie
®
Features Pen and product instructions.
• Terminates 110-style keystone blocks and jacks
• Lower cost, replace just the cutting knife 90152C
• Faster, cleaner terminations
Kit Includes:
• Professional Electrician’s
Scissors
• PT Punchdown Tool
• 110 Punchdown Blade
• Punchdown Tool Pouch
Part # Description
100111C Non-Impact Tool with Part # Description
110 EZ-Data Cut Blade ® 90152C PRO Punchdown Kit
13004BLC Replacement Knives (3)
