We Make Connections EZ! Crimpers

Open Barrel Contact Crimp Tool
Simultaneously performs electrical and strain relief crimps of 24-18 AWG open barrel
contact pins. Crimping cavities are precision ground and heat treated for long life.

Features
• 24-22 AWG and 20-18 AWG wire ranges
• Spring loaded for ease of use and
locking latch for storage
• Soft, comfortable molded handles
• Built-in wire cutter
Open Barrel Contacts
Part # Description
16801C Open Barrel Contact Crimp Tool

4-Way, 8 and 12 Point Indent Crimp Tools
®
An economical alternative to MIL-SPEC (MS22520) approved crimping tools.
Providing a higher level of reliability and greater pull strength, the dies are precision
machined from tool steel and heat treated for long life. The tools feature a full cycle
ratchet mechanism and include a built-in contact locator.
Features

• 4-Way, 8 point, or 12 point indent crimping styles
• Wire range: 26-20 AWG
13010C
• For use on solid barrel type contacts used in
RS-232 style connectors
• For use on BNC/TNC solid barrel center contacts

Part # Description
13010C 4-Way, 8 Point Indent Crimp Tool
13015C 4-Way, 12 Point Indent Crimp Tool
Solid Barrel Contacts
