LY SERIES HAND CRIMPING TOOLS

Ratchet type red anti-slip handles crimper. Original design.

For socket sleeves (female)
ROLLED shape crimping
Model No.: LY-03B Model No.: LY-03BM (Precise machining)
Crimping Range: Crimping Range:
DIN: 0.5-6mm DIN: 0.5-6mm
2
2
AWG: 20-10 AWG: 20-10
Tab width: 6.3mm Tab width: 6.3mm
Tool weight: 0.6kg Tool weight: 0.6kg
Tool lenth: 230mm Tool lenth: 230mm

Model No.: LY-48B Model No.: LY-63B
Crimping Range: Crimping Range:
2
DIN: 0.14-2.5mm DIN: 0.25-6mm
2
AWG: 26-14 AWG: 22-10
Tab width: 4.8/2.8mm Tab width: 6.3mm
Tool weight: 0.6kg Tool weight: 0.6kg
Tool lenth: 230mm Tool lenth: 230mm

Model No.: LY-29B Model No.: LY-04B
Crimping Range: Crimping Range:
DIN: 0.14-1.5mm DIN: 0.5-6mm
2
2
AWG: 26-16 AWG: 20-10
Tab width: 2.8mm Tab width: 6.3mm
Tool weight: 0.6kg Tool weight: 0.6kg
Tool lenth: 230mm Tool lenth: 230mm

crimper with locator to
set crimping materials Model No.: L0363/ L0348/ L4848

Model No.: LY-48B48L Locator accessory for
Model No.: LY-03B63L / LY-03B48L Crimping Range: socket sleeves fixed and
Crimping Range: DIN: 0.14-2.5mm easier crimping
2
DIN: 0.5-6mm AWG: 26-14 Tab width: 6.3 / 4.8 / 4.8 & 2.8
2
AWG: 20-10 Tab width: 4.8/2.8mm
Tab width: 6.3mm / 4.8mm Tool weight: 0.6kg
Tool weight: 0.6kg Tool lenth: 230mm
Tool lenth: 230mm
