Torque Wrench WPE Series - WiFi Mechatronic Preset

Main Features and Functions

● Accuracy: Torque: CW±4% from 20% to 100% of capacity;
Series
Angle: ( ±1% of reading) + ( ±1° @ angular speed of 10°/s~180°/s) +( ±1° of test fixture)
● LCD screen display, convenient for real-time viewing. The wrench can be adjusted against
the displayed torque value.
● Maintaining the Click audible alarm feature of the mechanical wrench.
● 4 Torque units are available: N.m, Ft.lb, In.lb, Kg.cm
● First peak value mode
● Adjustable mechanism to set the torque value setting, and minimum angle value can be set
in the system to prevent the operator from operating the same screw repeatedly.
● Peak value and judgment light status remain displayed after unloading.
● During continuous operation, the wrench will automatically reset to zero.
● Automatically shuts down after standby time.
● Battery level is displayed on the screen.
● Using 14500 high-capacity rechargeable lithium battery, which can be charged through the
Type-C port on the wrench. The battery can be removed and charged on a dedicated charger
for replacement, without delaying work.
● Centralized Control Softwares:

Synchronization via USB
WiFi Settings
x

Version of Wrench
Read Current version
Upgrade

WPE WiFi Server WPE USB Update
● Under the WiFi environment, the ● WiFi Server software can receive instant data from 24 wrenches working at the same time
and record the information. Each screen can observe 12 wrenches.
Network
● Through the USB Update software, you can set the : accuracy, angle value, etc. for judg-
ment, and download them directly into the wrench.
● 24 wrenches can be controlled at the
● The data of operating the wrench can be automatically sent to the centralized control center
and saved.
● For customers with development 4G/5G ● The wrench also has its own memory, which can save 1000 groups of data. If there is no
WiFi communication temporarily, the data will be automatically stored in the memory of the
protocols can be provided to enhance wrench and will be uploaded automatically after WiFi is restored. You can also upload the data
enterprise-level management of torquing. manually via the USB upload software.

Square Torque Range Length Width Weight
Rectangular Shank Head Holder Torque Wrench Item No.
Drive
Lb.ft
N.m
kg
mm
WPEMH Model For rectangular shank head inserts WPEMH930 9×12 6.0-30 50-250* 248 mm 0.55
vertical plane Optional WPEMH960 9×12 20-100 15-75 296 24 0.66
24
9-45
10-60
345
24
0.76
WPEMH9100
9×12
● The angle function of NovaTork is directed and devel
Fittings:
WPEMH14200 14×18 40-200 30-150
1.28
32
WPEMH14300 14×18 50-300 40-225 448 32 0.99
580
*Unit is Lb.in
tively recognized in any plane at any angle.
