Torque Wrench WE_B Series - WiFi System

● Angle function:

Angle function can be applied to the
requirement of reaching a certain torque and
● Accuracy: Torque: CW±1%, CCW±2% +1dight from 10% to 100% of capacity; then turning through a certain angle, or pure
Angle: ( ±1% of reading) + ( ±1° @ angular speed of 10°/s~180°/s) +( ±1° of test fixture) angle testing. Horizontal plane
- High-precision gyroscope angle chip
was specially developed for NovaTork by
a team of academic experts. Arbitrary plane
- Sensitive recognition of any plane and
any angle. vertical plane

● Two-way communication function: For example,
LED USB when you set the parameters on the wrench end,
the centralized control center can read the informa-
tion. You can also set the parameters from the
0 30.6 computer in the centralized control center and
29.4
OLED 0° 10° upload them to the wrench.
| |
03
● Remote locking function: The wrench can be
● 2.4" OLED color screen display locked through the centralized control center, then
● Menu operation, easy to set and use the wrench end is not allowed to modify any param- 12 Wrenches per page on the software
● 7 Torque units are available: eters.

● Data Storage: The data of operating the wrench can be automatically sent to the centralized control
● Two modes: Peak and Track center and saved. The wrench also has its own memory, which can save 2000 groups of data. If there is
● Target values can be set, with five Test Types available. no WiFi communication temporarily, the data will be automatically stored in the memory of the wrench
- Peak Torque test, target torque value can be set and will be uploaded automatically after WiFi is restored.
- Peak Angle test, target angle value can be set
- Peak Torque+Angle test, can set target torque and angle values Reversible Ratchet Head Torque Wrench Rectangular Shank Head Holder Torque Wrench
WEM_B Model WEMH_B Model
Both directions, 8° swing suitable for confined space For rectangular shank head inserts

● When the set torque or angle is reached, there’re sound, light and handle vibration alarms.
● During continuous operation, the wrench will automatically reset to zero.
● After one test is completed, there will be data waveform display. Matching Optional
● Application curves can be saved and viewed on the wrench. Sockets Fittings:
● 50 sets of parameters can be preset (parameters include torque unit, Metric Metric
Torque Range
Torque Range
target value, accuracy, mode, etc.). Item No. Square N.m Lb.ft Length Width Weight Item No. Square N.m Lb.ft Length Width Weight
kg
mm
Drive
mm
mm
kg
mm
Drive
● For the non-standard calculation of the head extension, it is not necessary to WEM260B 3/8" 6-60 30-300* 430 38 0.99 WEMH960B 9×12 6-60 30-300* 402 24 0.86
do calculation every time, input the coefficient once, and the actual value will be displayed on WEM2100B 3/8" 10-100 7.4-73.8 460 38 1.05 WEMH9100B 9×12 10-100 7.4-73.8 432 24 0.93
WEM3200B 1/2" 20-200 14.8-148 526 40 1.2 WEMH14200B 14×18 20-200 14.8-148 505 32 1.04
WEM3300B 1/2" 30-300 22.1-221 606 40 1.35 WEMH14300B 14×18 30-300 22.1-221 585 32 1.2
● The screen brightness can be adjusted. WEM3340B 1/2" 34-340 25-250 606 40 1.35 WEMH14340B 14×18 34-340 25-250 585 32 1.2
● The standby time can be adjusted, and the wrench will automatically shut down after the *Unit is Lb.in *Unit is Lb.in
For English Unit, please consult the supplier.
● Battery level is displayed on the screen.
● Using 18650 high-capacity lithium battery, which can be charged through the Type-C port on
the wrench. The battery can be removed and charged on a dedicated charger for replacement,
