Torque Wrench DC Series - Digi-Click Mechanical

Reversible Ratchet Head Torque Wrench Rectangular Shank Head Holder Torque Wrench
DCM Model DCMH Model
Both directions, 8° swing suitable for confined space For rectangular shank head inserts

Matching Optional
Sockets Fittings:
Series Metric Metric
Square Torque Range Increment Length Width Weight Shank Size Torque Range Increment Length Width Weight
Item No. Item No.
● Accuracy: ±4% of reading value in clockwise direction. Drive N.m Lb.ft N.m mm mm kg mm N.m Lb.ft N.m mm mm kg
● Set Torque is displayed on back-lit LCD screen, and the increment is 0.1 of unit. DCM260 3/8" 6-60 4.5-45 0.1 382 41 1.3 DCMH960 9x12 6-60 4.5-45 0.1 408 41 1.3
DCM2100 3/8" 10-100 7.4-74 0.1 450 45 1.4 DCMH9100 9x12 10-100 7.4-74 0.1 431 41 1.4
● Lowest torque value is 10% of capacity. DCM3140 1/2" 14-140 10.5-105 0.1 481 45 1.45 DCMH14140 14x18 14-140 10.5-105 0.1 492 41 1.45
● Torque can be displayed in 4 different units: N.m, Lb.ft, Lb.in, Kg.cm. DCM3200 1/2" 20-200 14.7-147 0.1 520 45 1.6 DCMH14200 14x18 20-200 14.7-147 0.1 510 41 1.5
● For operators who are used to using mechanical “Click”torque wrenches, the alarm of “Click” DCM3300 1/2" 30-300 22-220 0.1 585 45 1.8 DCMH14300 14x18 30-300 22-220 0.1 568 41 1.7
is maintained.
● Push/Pull end cap to secure the set torque value from accidental change.
● Various kinds of heads are available:
- DCM model: Reversible ratchet head, fine-tooth ratchets suitable for operation in confined 100% Calibrated Shockproof packaging
spaces requiring only 8 degrees swing. Unique serial number for each torque wrench, Specially designed for all series of
- DCMH model: Head holder for 9x12, 14x18mm rectangular shank heads. corresponding to the certificate of calibration “NovaTork” torque products

PF339100

End Cap Locking Structure
Pull to unlock

Turn the knob
to adjust the torque
Push to lock

Cbuufsz

19
