Adjustable (Click) Torque Wrench G Series - Micrometer Adjustable (Click)

Round Head Holder Torque Wrench
Reversible Ratchet Head Torque Wrench Rectangular Shank Head Holder Torque Wrench GMR Model
For round hole inserts
Both directions, 8° swing suitable for confined space
(English Unit) (English Unit) Optional
Fittings:
Metric
Round Hole Torque Range Increment Length Width Weight Round Hole Torque Range Increment Length Width Weight
Optional Item No. mm N.m Lb.ft N.m mm mm kg Item No. mm N.m Lb.ft N.m mm mm kg
Fittings:
GMR1612 φ16 2.5-12 20-105* 0.1 288 38 0.58 GMR16335 φ16 65-335 50-250 1 515 38 1.2
GMR1620 φ16 4.0-20 30-180* 0.1 288 38 0.58 GMR16400 φ16 80-400 60-300 2 695 38 2
GMR1630 φ16 6.0-30 50-250* 0.2 307 38 0.72 GMR22500 φ22 100-500 80-400 2.5 800 38 4.3
GMR1660 φ16 10-60 9-45 0.5 377 38 0.86 GMR22800 φ22 160-800 120-600 4 1005 38 5.2
GMR16125 φ16 25-125 20-90 0.5 431 38 0.94 GMR221000 φ22 200-1000 150-750 5 1005 38 5.2
GMR16200 φ16 40-200 30-150 1 455 38 1.06 GMR16335L φ16 65-335 50-250 1 695 38 2
*Unit is Lb.in; L is extended length version

Model With Extension (Model number with last letter “E”)

Screw in ...................................... Fix
......................................

Metric Metric
Square Torque Range Increment Length Width Weight Exten- Shank Size Torque Range Increment Length Width Weight Exten-
Item No. Item No.
Drive N.m Lb.ft N.m mm mm kg sion mm N.m Lb.ft N.m mm mm kg sion
GM51500E 1" 300-1500 200-1100 5 2200 75 12.1 1 GMH271500E 27x36 300-1500 200-1100 5 2200 64 12.5 1
GM52000E 1" 400-2000 300-1500 10 2200 75 12.1 1 GMH272000E 27x36 400-2000 300-1500 10 2200 64 12.5 1
GM53000E 1" 600-3000 400-2000 15 2780 75 15.5 1 GMH273000E 27x36 600-3000 400-2000 15 2780 64 15.3 1

English
100% Calibrated Shockproof packaging

Unique serial number for each torque wrench, Specially designed for all series of
corresponding to the certificate of calibration “NovaTork” torque products

PT223983
