Adjustable (Click) Torque Wrench G Series - Micrometer Adjustable (Click)

Reversible Ratchet Head Torque Wrench Rectangular Shank Head Holder Torque Wrench
GM Model GMH Model
Both directions, 8° swing suitable for confined space For rectangular shank head inserts
G Model (English Unit) GH Model (English Unit)

Optional
Matching
Sockets Fittings:
Metric Metric
Square Torque Range Increment Length Width Weight Shank Size Torque Range IncrementLength Width Weight
Item No. Item No.
Drive N.m Lb.ft N.m mm mm kg mm N.m Lb.ft N.m mm mm kg
GM112 1/4" 2.5-12 20-105* 0.1 290 38 0.68 GMH912 9x12 2.5-12 20-105* 0.1 284 38 0.58
GM120 1/4" 4.0-20 30-180* 0.1 290 38 0.68 GMH920 9x12 4.0-20 30-180* 0.1 284 38 0.58
Series GM230 3/8" 6.0-30 50-250* 0.2 318 38 0.82 GMH930 9x12 6.0-30 50-250* 0.2 303 38 0.72
GM330 1/2" 6.0-30 50-250* 0.2 318 38 0.82 GMH960 9x12 10-60 9-45 0.5 372 38 0.86
GM260 3/8" 10-60 9-45 0.5 388 38 0.96 GMH9100 9x12 20-100 15-75 0.5 427 38 0.94
● Accuracy: ±4% in clockwise direction from 20% to 100% of capacity. GM360 1/2" 10-60 9-45 0.5 388 38 0.96 GMH9125 9x12 25-125 20-90 0.5 427 38 0.94
● All steel construction, superb durability. GM2100 3/8" 20-100 15-75 0.5 443 38 1.04 GMH14200 14x18 40-200 30-150 1 459 38 1.06
● Permanently stamped major and minor scales for precision torque values setting. GM3100 1/2" 20-100 15-75 0.5 443 38 1.04 GMH14335 14x18 65-335 50-250 1 514 38 1.2
GM2125 3/8" 25-125 20-90 0.5 443 38 1.04 GMH14400 14x18 80-400 60-300 2 697 35 2.1
● Convenient Metric or English major scale with English or Metric secondary scale. GM3125 1/2" 25-125 20-90 0.5 443 38 1.04 GMH24500 24x32 100-500 80-400 2.5 855 56 5
● Set torque by locking ring. The rebound self-locking structure can reliably lock the required torque. GM3200 1/2" 40-200 30-150 1 468 40 1.16 GMH24800 24x32 160-800 120-600 4 1055 56 5.9
GM3335 1/2" 65-335 50-250 1 528 40 1.3 GMH241000 24x32 200-1000 150-750 5 1055 56 5.9
● Grooved non-slip grip fits comfortably in your hand. GM4335 3/4" 65-335 50-250 1 528 40 1.34 GMH271500 27x36 300-1500 200-1100 5 1249 64 9
● Various kinds of heads designed for different applications: GM4500 3/4" 100-500 80-400 2.5 855 60 5 GMH272000 27x36 400-2000 300-1500 10 1249 64 9
- GM / G model: Reversible ratchet head, f GM4800 3/4" 160-800 120-600 4 1055 60 5.9 GMH273000 27x36 600-3000 400-2000 15 1249 64 10.3
GM5800 1" 160-800 120-600 4 1055 60 5.9 GMH14335L 14x18 65-335 50-250 1 694 38 2
for operation in confined spaces requiring only 8 degrees swing. GM41000 3/4" 200-1000 150-750 5 1055 60 5.9 GMH24400S 24x32 80-400 60-300 2 697 56 2.8
- GMH / GH model: Head holder for standard 9x12, 14x18, 24x32, GM51000 1" 200-1000 150-750 5 1055 60 5.9 GMH14500S 14X18 100-500 80-400 2.5 674 56 3
GM51500 1" 300-1500 200-1100 5 1260 75 9.2 GMH24500S 24x32 100-500 80-400 2.5 697 56 3
27x36mm rectangular shank heads. GM52000 1" 400-2000 300-1500 10 1260 75 9.2 *Unit is Lb.in; L is extended length version; S is shortened length version.
- GMR model: Round head holders for Ф16, Ф22mm heads. GM53000 1" 600-3000 400-2000 15 1260 75 10.5 English
GM3200L 1/2" 40-200 30-150 1 525 40 1.29
Shank Size Torque Range Increment Length Width Weight
GM3335L 1/2" 65-335 50-250 1 700 40 2.1 Item No.
mm Lb.ft N.m Lb.ft mm mm kg
GM4335L 3/4" 65-335 50-250 1 700 40 2.15
GH9200 9x12 40-200* 4.0-22 1* 265 38 0.58
GM51500L 1" 300-1500 200-1100 5 1600 75 13
GH9250 9x12 50-250* 6.0-30 1* 300 38 0.72
GM52000L 1" 400-2000 300-1500 10 1600 75 13
GH9100 9x12 20-100 25-135 0.5 410 38 0.94
Upsrvf!Mpdljoh GM53000L 1" 600-3000 400-2000 15 1840 75 15.2 GH14150 14x18 30-150 40-200 0.5 493.5 38 1.06
GM4400S 3/4" 80-400 60-300 2 697 57 3.1
GH14250 14x18 50-250 70-340 1 513.5 38 1.2
GM4500S 3/4" 100-500 80-400 2.5 700 57 3.1
GH24400 24x32 80-400 100-550 2 855 56 5
*Unit is Lb.in; L is extended length version; S is shortened length version.
GH24600 24x32 100-600 150-800 2.5 1055 56 5.9
English GH271000 27x36 200-1000 250-1350 5 1260 64 9
Square Torque Range Increment Length Width Weight GH272000 27x36 400-2000 500-2700 10 1260 64 10.3
Item No.
Drive Lb.ft N.m Lb.ft mm mm kg GH14250L 14X18 50-250 70-340 1 700 38 2
G1200 1/4" 40-200* 4.0-22 1.0* 280 38 0.68 *Unit is Lb.in; L is extended length version
G2250 3/8" 50-250* 6.0-30 1.0* 315 38 0.82
G2100 3/8" 20-100 25-135 0.5 425 38 1.04
G3100 1/2" 20-100 25-135 0.5 425 38 1.04
G3150 1/2" 30-150 40-200 0.5 505 40 1.16
G3250 1/2" 50-250 70-340 1 525 40 1.3
G4250 3/4" 50-250 70-340 1 525 40 1.34
G4400 3/4" 80-400 100-550 2 855 60 5
G4600 3/4" 100-600 150-800 2.5 1055 60 5.9
G5600 1" 100-600 150-800 2.5 1055 60 5.9
G51000 1" 200-1000 250-1350 5 1260 75 9.2
G52000 1" 400-2000 500-2700 10 1260 75 10.5
G3250L 1/2" 50-250 70-340 1 705 40 2.1
G4250L 3/4" 50-250 70-340 1 705 40 2.15
*Unit is Lb.in; L is extended length version.
