Cable Shears

(ratchet mechanism)

with telescopic handles

► Cable shears with adjustable telescopic handles 95 32 038
allowing angular positioning

> For cable diameters up to 38 mm, handles can be positioned at
an angle to set the optimum handle width, which makes the shear Handles adjustable in length and angular position for easier work:
also suitable for work in confined areas set the handle length to the optimum lever for powerful cutting;
> Comfortable work due to ratchet action and low weight put the handles at an angle for a comfortable gripping position
> Heavy duty telescopic handles made of oval aluminium tubing;
extendable up to 770 mm for maximum leverage on large cable
diameters; retractable down to 570 mm for minimum space
requirements during transport
> Replaceable cutting head
> Extensive cutting range up to max. Ø 38 mm or max. 280 mm²
(e.g. 4 x 70 mm² NYY) in copper and aluminium cables
> Easier, neater cut due to optimised cutting edge geometry
> Adjustable bolted joint
> Handles: high-strength oval aluminium tubing
> Cutting head: special quality high-grade tool steel, oil-hardened

Cutting capacities
EAN
Article No. 4003773- mm Head Handles Ø mm mm² MCM g
95 32 038 071556 570 burnished with multi-component grips 38.0 280 550 1980
95 39 038 073260 Spare cutter head for 95 32 038

Cable Cutters

(ratchet mechanism)

with telescopic handles
> For copper and aluminium single conductors as well as multiple
stranded cables – also with hard rubber or plastic sheath
> Not suitable for steel wire, wire ropes and fine-stranded (highly 95 32 060
flexible) conductors
> Also suitable for cables with iron sheath reinforcement
> Little hand force required for cutting due to optimum transmission ratio
> High cutting capacity due to two-hand operation and ratchet mechanism
> The blade can be opened in any cutting position
> Handle length with multiple position adjustment from 400 – 610 mm
(short transport length, individual adaptation to working conditions)
> Blade: special-quality high-grade tool steel, oil-hardened
> Handles: high-strength oval aluminium tubing
95 32 060
> Tool in length: 600 to 810 mm; weight only approx. 3820 g
95 32 100
> Tool in length: 650 to 860 mm; weight only approx. 4980 g
Cutting capacities
EAN
Article No. 4003773- mm Head Handles Ø mm mm² MCM g
95 32 060 071563 630 burnished with multi-component grips 60.0 740 1400 3820
95 32 100 071570 680 100.0 960 1900 4980
95 39 720 025290 Movable spare blade for 95 31 720 / 95 32 060
95 39 870 025306 Movable spare blade for 95 31 870 / 95 32 100

176 I CABLE AND WIRE ROPE SHEARS
