Pliers

Strippers, Cutters, and Crimpers WIRE PULLING GRIPS

Drivers and Wrenches

TYPES OF WIRE PULLING GRIPS

TM
TM
Conduit Tools and Measurement Klein Chicago , Parallel Jaw and Haven's Grips are widely used in the power, communications, and general construction fields
to pull wire and cable. The grips maintain temporary tension until the wire or cable can be permanently terminated.
™
Chicago Grips
Designed for use on aluminum, copper,
weatherproof coated wire, PVC covered
Tool Kits conductors and messenger and guy strand Single V Double V Round Aggressive
Jaw
Jaw
Jaw
Jaw
•
Locking loop handles allow the jaws to be held in an open
position for easy placement on wire or cable Contour Contour Contour Contour
• Available in Round, Double V, Single V and 1656-30
Aggressive jaw contours
Safety, PPE and Comfort Parallel Jaw Grips
Lightweight compact grips pull an exceptionally
wide range of cable types and sizes Double V Round
Jaw Jaw
• Latch helps maintain cable position Contour Contour KT4500
Jobsite Accessories • Large-diameter eye accommodates large hooks on hoists,
winches and tackle blocks
•
Available in Round and Double V jaw contours

Tool Storage Haven's Grips
™
Designed for use when a light, compact grip is desired where
conductor deformation is not a factor
• Knurled eccentric jaw applies gripping pressure to 1/4" of cable area
• Some models include a swing latch that holds cable securely in jaw 1625-20
Voice/Data/Video • 1625 Series can be used for wire rope
•
Recommended for messenger and guy strand and wire rope

Hot-line Latch
Designed for placing a grip on cable with a hot-line stick Selecting the Proper Grip
Test and Measurement • The three notches in the hot-line latch adjust the balance of the grip to better match the direction of the cable sag
• When stick is removed, latch closes automatically to guard against grip accidentally disengaging from wire
• Standard hot-line grips are not supplied with springs or lock-open features
• Some grips are available with a positionable latch

Power Tools and Accessories Wire Pulling Grips Warnings WARNING: Do not exceed rated capacity.
Wire Pulling Grips Warnings

WARNING: Always match proper size and type of grip to application.
WARNING: Grips are to be used for temporary installation, not for permanent anchorage.
WARNING: Before each use, clean jaw area and inspect grip for
Lifting, Pulling, Lifting, Pulling, & Structural and Structural 290 WARNING: When used on/or near energized lines, ground, insulate, or isolate grip before pulling. proper operation to avoid slippage.

www.kleintools.com > 800-553-4676
