Specialty tools Specialty tools

Chassis – Wheel bearing / Wheel hub Chassis – Wheel bearing / Wheel hub

4915 Shock absorber tool set 2710 Camber adjustment specialty tool

Made in Germany NbYc8 C/ Made in Germany r8 C
• Application: Repair work at the • Specialty tool, tuned to the extremely hard-to-access
spring strut e.g. shock absorber, strut mounting, coil spring shock absorber screw connection
• Retaining the piston rod when removing and installing the spring strut
G • Attention: Follow vehicle manufacturer’s specifications • Application: Shock absorber screw connection for camber
adjustment on MERCEDES-BENZ Sprinter, VW Crafter
concerning torque tightening values
– Use with torque wrench e.g. HAZET 6291-1CT together
with insert box-end wrench 6630d-21 • Specialty tool enables:
– Operation even with unfavourable spatial conditions on a measurement platform
Application of an impact wrench may damage the The necessary force transmission for screwing operation
thrust bearing and the piston rod

F

1 4
2710-21 206414
D Wheel bearing / Wheel hub

606 • % 4910 • b • 8 4910 • N • 8
21 6 • 7 • 8 T 50 1779 Ball joint puller
Made in Germany C
4910 • c 4910 • Y • 8 • Application: Removing the ball joint pivots
16 • 17 • 18 • 19 Y 5 x 8 • Y 6 x 8 of steering tie rods, stabilizers, etc.
21 • 22 • 24 Y 7,1 x 9,6 • ä = Jaw opening
R 1 L x W x H è 4 • Surface: galvanised

mm
4915/15 355 x 235 x 65 15 179213

2593 Shock absorber crown wrench

Made in Germany CF
C • Application: Operation of shock absorber screw connections
(repairs)
on VW ∙ SEAT ∙ AUDI
vehicles (front axle)
• n drive 22 mm, b = width of pins
• Surface: chrome-plated 1 1 5 a 4
1779-27 27 54 54 136025
1779-37 37 75 77 136032
• E.g. for commercial vehicles MAN ∙ MERCEDES-BENZ etc.
1779-55 55 81.3 80 136407
O
1 h t 5 4 1779 Universal ball joint puller

2593-4 22 14.5 5 017263 Made in Germany C
• Application: Removing the ball joint pivots (jaw
opening 23 mm) of steering arms, steering tie rods,
2780 Shock absorber crown wrench stabilizers etc. on the most common vehicles
• Great clamping range due to continuous vertical
adjustment and turn-over of the lower part
Made in Germany C
A • Application: Operation of shock absorber screw connections (upper
journal fitting)
on MERCEDES-BENZ type 203
(C-Class model year 2000→)
• n drive 22 mm, b = width of pins
• Surface: chrome-plated

U

1 h t 5 4 1 1 U 4
2780-1 22 14.1 2.6 082858 1779-1 23 65 135974
