Specialty tools

Chassis – Spring vices / Shock absorbers

4902 Inside spring vice set 4904 Universal inside spring vice

Made in Germany C/ Made in Germany C/
• Application: Installation and removal of the coil spring on the rear axle • Compact HAZET design enables spring
• Optimally coordinated to the confined spaces in the following vehicles replacement with remarkable time savings
BMW • Universal application on almost all passenger cars
1 Series
– E87 Hatchback model year 2003 → 2011 • Application: Installation and removal of the coil spring on the rear axle G
– E81 Hatchback model year 2006 → 2013 • Anti-rotation device for lower tensioning jaws integrated in the base component
– E82 Coupé 2006 → 2014 reduces the outer diameter to only 32 mm thanks to compact design
– E88 Convertible model year 2007 → 2015 • Pendulum hexagonal head for equal force distribution with
– F20 ∙ F21 model year 2011 → 2019 integrated anti-rotation protection for upper tensioning jaws
• 2 Series
– F22 ∙ F23 ∙ F87 model year 2013 → • One-sided counterholder for the spindle made possible by hexagon
on top, e.g. with combination wrench HAZET 600N-13
• 3 Series • Removal and installation of springs with small coil spacing, e.g.
– E90 → Notchback model year 2004 → 2012 for the MINI Cooper S (third generation) ∙ VW Passat (B8)
– E91 → Touring model year 2004 → 2013
– E92 → Coupé model year 2005 → 2013 • Extension of the span to 120 mm and an increase of the maximum
– E93 → Convertible model year 2005 → 2013 load for increasing vehicle weights (electric and hybrid vehicles), F
– F30 ∙ F31 ∙ F34 ∙ F35 ∙ F80 model year 2011 → 2019 for safe working up to 31,000 N → Tested with at least four-
• 4 Series fold safety against breakage (GS mark of tested safety)
– F32 ∙ F33 ∙ F36 ∙ F82 ∙ F83 model year 2013 → 2020 • 17° angular movement of the tensioning jaws now ensures removal of
• X1 C-shaped (bent) springs, e.g. on the AUDI A4 (B9) ∙ VW Golf 7
– E84 model year 2009 → 2015 • Internal and external guidance of the tensioning
• Pendulum 6-point head provides a uniform distribution jaws prevents the spring from sliding out
of power with the integrated twist protection • All tensioning jaws included, reusable, replaceable plastic protective pads
• Internal guidance of the tensioning jaws • Tested on vehicles from the following manufacturers:
prevents the spring from sliding out AUDI ∙ BMW ∙ CITROËN ∙ FIAT ∙ FORD ∙ HYUNDAI ∙ KIA ∙
• Both-sided spindle operation possible MAZDA ∙ MERCEDES BENZ ∙ MINI ∙ OPEL ∙ PEUGEOT ∙ RENAULT ∙ SEAT ∙
ŠKODA ∙ TOYOTA ∙ VOLKSWAGEN
• Plastic box YouTube Clip Highlights: D
• Easy handling for just one user
• Eliminates time-consuming work associated
with most spring removal:
– Removal of axle parts unnecessary
– Axle alignment no longer necessary
– Removal and installation possible in
just a few minutes on each side
• Plastic box
• Soft foam insert
R

Video C

1 t è 4 O

• 6-piece set, contents:
– 1 inside spring vice 4904-1
– 1 tensioning jaw 4904-10 ∙ span width 64 – 115 mm
– 1 tensioning jaw 4904-11 ∙ span width 64 – 115 mm
1 K t è 4 – 1 tensioning jaw 4904-12 ∙ span width 79.5 – 133 mm
– 1 tensioning jaw 4904-13 ∙ span width 79.5 – 133 mm
• Inside spring vice set, contents: – 1 tubular box wrench 4902-224 ∙ s 24 mm
4902-1 ∙ 10 ∙ 11 ∙ 210 ∙ 224 4904/6 – 6 238897
4910-1 • Inner spring vice: spindle ∙ drive nut ∙ pressure sleeve with anti-rotation device A
4902/6 – – 6 121694 4904-1 – – 236251
• Inside spring vice • Tensioning jaw ∙ span width 64 – 115 mm
4902-1 – – – 122639 4904-10 64 – 115 – 236213
• Tensioning jaw 4904-11 64 – 115 – 236220
4902-10 – 95 – 100 – 122646 • Tensioning jaw ∙ span width 79.5 – 133 mm
4902-11 – 95 – 100 – 122653 4904-12 79.5 – 133 – 236237
• Tubular box wrench, size 10 mm 4904-13 79.5 – 133 – 236244
4902-210 – – – 122677 • Plastic protective pad (2 piece)
• Tubular box wrench, size 24 mm 4904-100/2 – – 240036 U
4902-224 – – – 122660 4904-120/2 – – 240043
• Reversible ratchet 4912-6 – – 238835
• Output: 12-point 21 mm • Tubular box wrench, size 24 mm
4910-1 275 – – 062133 4902-224 – – 122660

Components and spare parts from page 500 to 509 Errors excepted 455
