Specialty tools Specialty tools

Chassis – Spring vices / Shock absorbers Chassis – Spring vices / Shock absorbers

Product applications 4900 Safety spring vice set
Safety spring vice database
hazet.de à Service à Tool Finder Made in Germany
à Safety spring vice database C/
• Suitable for impact wrenches
C For Smartphones with QR reader (app)
• Application: Installing and removing the coil spring
G 4900 Safety spring vice basic unit • Closed system – maintenance-free
when replacing shock absorbers
Made in Germany C/ • Variable system thanks to easily replaceable tensioning jaws
• Plastic inserts for the protection of the lacquered spring surfaces.
• Installing and removing the coil spring when changing shock This prevents spring damage due to corrosion
absorbers • Location bar for machinist‘s vice
Suitable for around 200 different vehicle types
• 4900-2A also for spring strut with rebound spring in the shock absorber
• Maximum span: 309 mm
• Application: Coil spring when changing shock absorber (please note safety
spring vice classification table on the Internet or in the tool catalogue) • High capacity of 26000 N
• Maximum span: 309 mm • GS mark – tested safety
F • High capacity of 26000 N • Tempered cylindrical and guiding tube
• Forged and tempered tensioning jaws
• Suitable for impact operation, e.g. HAZET 9012EL-SPC or 9012MT
together with HAZET socket 900S-27 or 900SLG-27
• Closed system – maintenance-free
• Variable system thanks to easily replaceable tensioning jaws
• Location bar for machinist‘s vice
• GS mark – tested safety
• Tempered cylindrical and guiding tube
• Forged and tempered tensioning jaws
• Also for spring strut with rebound spring in the shock absorber
D

R

YouTube Clip 4900-2 A/3 YouTube Clip
1 t 4 1 è 4
C Safety spring vice basic unit • 1 basic unit and 2 tensioning jaws 4900-11

4900-2 A – 077267 • Suitable for around 50 different vehicle types
• Replacement set ∙ for spring vice 4900-1A and -2A • Plastic inserts optionally available
consisting of 2 straight pins and 1 O-ring 4900-2 A/3 3 149483
4900-02 A/3 7 069415 • 1 basic unit and 4 tensioning jaws (2x 4900-11 and 2x 4900-12)
• Replacement set ∙ for spring vice 4900-1 and • Suitable for around 100 different vehicle types
4900-2 consisting of 5 straight pins and 2 O-rings • Plastic inserts optionally available
4900-02/7 6 063437 4900-2 A/5 5 086054
O

4900 Tensioning jaw 4900 Tensioning jaw

Made in Germany C Made in Germany C

A

4900-100 4900-110

t
t
U 1 69 – 120 4 1 107 – 151 4
4900- 11
4900- 10
059706
059713
• Plastic insert for protection of the lacquered spring • Plastic insert for protection of the lacquered spring
surfaces preventing coil damage due to corrosion surfaces preventing coil damage due to corrosion
4900-100 – 061136 4900-110 – 061143
452 Errors excepted Components and spare parts from page 500 to 509
