Specialty tools Specialty tools

Chassis – Spring vices / Shock absorbers Chassis – Spring vices / Shock absorbers

4912 Support device 4903 Universal spring vice

Made in Germany C C C/
• Can be used on almost all vehicles – helpful on vehicles with multi-link
axle
G • Application: Prevents unwanted raising of the 4903-2
chassis during a spring tensioning process
• Protective pads prevent damage to the vehicle parts
• Facilitates removal of rear axle springs 4903-3
• Safety: visual chain provides a reminder for tool removal
• Use together with universal inside spring vice set 4904/6
• Clamping range: 80 – 127 mm
• Thrust block diameter: 30 mm 4900-2 A
• Chain length: 750 mm 4903-1
F

1 4 4903/2 4903/3
D 4912-6 238835

4903 Universal spring vice

Made in Germany C/
• Increased safety – thanks to load-free installation
• Can be used for almost any spring strut / shock absorber strut
• Load-free disassembly / assembly with completely relieved shock absorber
R Innovative socket and installation concept
• Swivels in horizontal or vertical working position,
HAZET recommends ergonomic working height:
adjust vertically, operate horizontally
• Damage to shock absorbers and head plates impossible 1 è 4
(no overload risk)
• Simple, lockable strut mount • Basic support for the installation of the safety spring
High safety vice basic unit (including safety adapter)
• Consistently reliable mounting of head plates • Perfect basic equipment if the basic unit 4900-2A already exists
• Thread damage to piston rod impossible 4903-1 – 179824
C • Permanent fixation of spring throughout operation • By using the clamping disc and the universal tensioning
Secured investment – by using existing components of SYSTEM 4900
• Existing basic units 4900-2A and all tensioning jaws of System 4900 may be used jaw, the basic support 4903-1 or the set 4903/2A becomes
a completely stationary universal spring vice
• Use of future applications is assured • 2-piece set, contents:
Allows record keeping by scaling • 4903-2 universal clamping disc ∙ adjustable
• If recurring, significant time savings by scaling • 4903-3 universal tensioning jaw ∙ adjustable, safety adapter included
• Firm fixation eliminates readjustment at the 4903/2 2 180530
same spring strut (left/right)
4 steps to success: • Perfect choice, if the safety spring vice basic unit 4900-2A already exists
1. Fix spring strut on clamping disc • 3-piece set, contents:
O 2. Grip spring with universal tensioning jaw • 4903-1 basic support
via gripper and brakes
• 4903-2 universal clamping disc ∙ adjustable
3. Operate tensioning device • 4903-3 universal tensioning jaw ∙ adjustable, safety adapter included
with reversible ratchet, 4903/3 3 180554
cordless screwdriver or • The perfect complete package
pneumatic air ratchet
4. Disassemble shock absorber • 4 pieces, contents:
without load and install new • 4900-2A safety spring vice basic unit
one • 4903-1 basic support
(afterwards in reverse order) • 4903-2 universal clamping disc ∙ adjustable
• 4903-3 universal tensioning jaw ∙ adjustable, safety adapter included
A 4903/4 4 180561
• Universal clamping disc, adjustable
4903-2 – 179831
• Universal tensioning jaw ∙ adjustable
4903-3 – 179848
Safety spring vice basic unit
• Coil spring when changing shock absorber (please note safety spring
vice classification table on the Internet or in the tool catalogue)
4900-2 A – 077267
U • Replacement set ∙ for universal spring vice
4903-1 consisting of 2 straight pins and 1 O-ring
4903-01/3 – 181704
YouTube Clip • Brake for 4903-1
B 4903-04 – 226351
