Pneumatic tools ∙ Cordless tools

Impact wrenches

9013 TT 3/4″ Twin Turbo impact wrench ∙ 9014 TT 1″ Twin Turbo impact wrench ∙
long spindle long spindle
C • Loosening torque: 3850 Nm
4 / 5 /
• Exhaust air is guided through the handle downwards
• Reduced vibrations
• Easy handling
• Short, compact design with 240 mm long spindle
• One-hand operation for left- and right-handed users
• Removable handle, 360° adjustable
• Connecting socket for low noise hose
9040-013
• HAZET Twin Turbo technology – high torques with compact design
• 8-blade air motor with 25% higher impact performance ensures maximum torque
• Powerful twin hammer mechanism
• Air connection inlet: inside thread 20.67 mm ( ⁄2″)
1
• Coupler plug: nominal size 10 (included)
• Recommended torque: 1627
• Hose diameter (recommended): 19 mm
• Working pressure (bar): 6.3
• Sound power level: 113.5 db(A) Lp W
• Vibration acceleration: 17.31 m/s 2
1 Nm Y l/min. rpm db (A) LpA 5 4 • Loosening torque (max) determined with screw size M: 32
Ú
N
?
^
Nm
9013 LGTT 3800 2020 243 5200 102.5 5500 232277 • Forward and reverse: two-stage (forward),
single-stage (reverse)
Low noise hose for noise reduction of the HAZET Turbo Twin impact wrenches • Cold insulated handle
9013TT ∙ 9013Lg TT
Spring clamp for fixing the hose to the handle
9040-013 – – – – – – 232994
9014 TT 1″ Twin Turbo impact wrench
• Loosening torque: 4100 Nm 5 /
• Exhaust air is guided through the handle downwards
• Reduced vibrations
• Easy handling
• Short, compact design
• One-hand operation for left and right handers
• Removable handle, 360° adjustable
• Connecting socket for low noise hose
• HAZET Twin Turbo technology – high torques with compact design
• 8-blade air motor with 25% higher impact performance ensures maximum torque
• Powerful twin hammer mechanism
1
• Air connection inlet: inside thread 20.67 mm ( ⁄2″)
• Coupler plug: nominal size 10 (included)
• Recommended torque: 1898
• Hose diameter (recommended): 19 mm
• Working pressure (bar): 6.3
• Sound power level: 112.9 db(A) Lp W
• Vibration acceleration: 19.11 m/s 2
• Loosening torque (max)
determined with screw size M: 32
• Forward and reverse: two-stage
(forward), single-stage (reverse)
• Cold insulated handle 1 Ú Y ? ^ N 5 4
Nm Nm l/min. rpm db (A) LpA
9014 LGTT 3850 1762 235 4600 102.5 5900 234677

YouTube Clip

1 Ú Y l/min. rpm db (A) LpA 5 4
?
N
^
Nm
Nm
9014 TT 4100 2170 235 5200 101.9 4600 234684
Components and spare parts from page 500 to 509 Errors excepted 347
