Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Impact wrenches Impact wrenches

9012 M 1/2″ Impact wrench ∙ extra short 9012 PTT 1/2″ Twin Turbo palm impact wrench

• Loosening torque: 1200 Nm 3 / C
• Exhaust air is guided through the handle downwards 3
• Reduced vibrations
• Easy handling
• Extra short – only 80 mm
• Single hammer striking mechanism
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Recommended torque: 610
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 103.2 db(A) Lp W
• Vibration acceleration: 13.49 m/s 2
• Loosening torque (max) determined with screw size M: 16
• Forward and reverse: three-stage (forward), single-stage (reverse)
• Cold insulated handle
?
Ú
N
^
• One-hand operation for right and left-handed operators 1 Nm Y l/min. rpm db (A) LpA 5 4
Nm
9012 PTT 550 500 113 8000 92.9 1100 252732
9012 ATT 1/2″ Twin Turbo impact wrench
• Loosening torque: 550 Nm 3 /
• Exhaust air is guided through the handle downwards
YouTube Clip • Reduced vibrations
• Easy handling
• Handle / trigger adjustable around its own axis for
optimal handling allows operation in any position
• Swivel mechanism for extended application
range guarantees best accessibility
• Short, compact, angled design – only 70 mm
• One-hand operation for left- and right-handed users
• Powerful twin hammer mechanism
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Recommended torque: 450
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 101.1 db(A) Lp W
9012 M-1-S • Vibration acceleration: 4.89 m/s 2
• Loosening torque (max) determined with screw size M: 16
1 Ú Y ? ^ N 5 4 • Forward and reverse: single-stage (right/left)
rpm
Nm
Nm
92.2
9012 M-1 1200 678 l/min. 8800 db (A) LpA 1270 218356 • Cold insulated handle
127.4
Silicone protective cover for 9012M-1
9012 M-1-S – – – – – – 222735
9012 PTT 1/2″ Twin Turbo palm impact wrench
YouTube Clip
• Loosening torque: 550 Nm
3
• Exhaust air is guided through the handle downwards
• Reduced vibrations
• Easy handling
• Extremely compact
• Low reaction forces
• HAZET Twin Turbo technology
• Recommended accessories: Rotary joint 9000-041
• Powerful twin hammer mechanism
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Recommended torque: 450
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 103.9 db(A) Lp W
• Vibration acceleration: 7.64 m/s 2
• Loosening torque (max) determined with screw size M: 16
• Forward and reverse: single-stage (right/left)
• Cold insulated handle

1 Ú Nm l/min. rpm db (A) LpA 5 4
N
^
Y
?
Nm
B 9012 ATT 550 500 113 8000 90.1 1300 234738
344 Errors excepted Components and spare parts from page 500 to 509
