Torque technology Torque technology

SYSTEM 6300 CT Insert tools

6300 Torque wrench ∙ ±2% accuracy ∙ 5 – 85 Nm

Made in Germany B /
• Accuracy ± 2% (6391-10: 6%) of the scale value (in direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool
• Plug-and-socket connection to hold insert tools
• Permanently adjustable value
• Especially suitable for application in industrial series production
• Adjustment of the desired torque value with adjustment wrench 6399 together
with HAZET torque tester 7901E ∙ 7902E ∙ 7903E or any other suitable device
• All wrenches of this series (HAZET 6391-6392) are without a scale
• With calibration certificate and serial number
• DIN EN ISO 6789-2:2017

1 Output K M N 1 5 Release accuracy ! # 4
tolerance %
6391-50 ) 9 x 12 241 201 30 17 22 2 5 – 50 2.2 – 22.1 027064
6391-85 ) 9 x 12 316 276 30 17 22 2 15 – 85 5.0 – 28.3 027071
• Factory preset triggering value as requested
6391-50 V ) 9 x 12 241 201 – 17 22 2 5 – 50 2.2 – 22.1 145881
6391-85 V ) 9 x 12 316 276 – 17 22 2 15 – 85 5.0 – 28.3 145898

6300 Torque wrench ∙ ±2% accuracy ∙ 50 – 320 Nm

Made in Germany D /
• Accuracy ± 2% (6391-10: 6%) of the scale value (in direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool
• Plug-and-socket connection to hold insert tools
• Permanently adjustable value
• Especially suitable for application in industrial series production
• Adjustment of the desired torque value with adjustment wrench 6399 together
with HAZET torque tester 7901E ∙ 7902E ∙ 7903E or any other suitable device
• All wrenches of this series (HAZET 6391-6392) are without a scale
• With calibration certificate and serial number
• DIN EN ISO 6789-2:2017

1 Output K M N 1 5 Release accuracy ! # 4
tolerance %
6392-200 ) 14 x 18 401 359 38.5 23 30 2 50 – 200 12.8 – 51.4 027118
6392-320 ) 14 x 18 631 589 38.5 23 30 2 60 – 320 9.8 – 52.0 027125
• Factory preset triggering value as requested
6392-200 V ) 14 x 18 401 359 – 23 30 2 50 – 200 12.8 – 51.4 145904
6392-320 V ) 14 x 18 631 589 – 23 30 2 60 – 320 9.8 – 52.0 145911

6399 Adjustment wrenches

Made in Germany
• For torque wrenches HAZET 6391 to 6392 (V)

1 K 4
6399 167 027170
324 Errors excepted Components and spare parts from page 500 to 509
