Torque technology Torque technology

SYSTEM 7000 sTAC SYSTEM 7000 sTAC

SYSTEM 7000 sTAC

7000 STAC Torque wrench with built-in angle gauge ∙ electronic ∙
SmartTAC SYSTEM 7000 sTAC ∙ 1–1000 Nm
Made in Germany
• Smart technology – Ready for Industry 4.0 • Four signals alert the user during screwing process: audible signal
(buzzer), vibration signal, synchronous numerical display, and a 360°
• HAZET Smart technology consisting of the SmartTAC app and Bluetooth 4.1 Low LED display with „traffic light function“ that is visible from all around
Energy interface (product group 7000-2sTAC may be subject to national approval • Threshold value, pre-warning level: adjustable 50 to 99%
restrictions). Smooth live data exchange for displaying the screwing progress • Adjustable signaling, On/Off audible signal (buzzer) and vibration
on mobile end devices, such as smartphones (smart watches) and tablet PCs. • Reset function, restore to factory setting
USB-C interface for programming torque wrenches with built-in angle gauge and • Stand-by time: adjustable 1 to 10 minutes
documenting the screwing data via laptop and PC with the software SmartTAC
tool 7910-sTAC. • Indication of battery condition and memory
All sTAC torque wrenches with built-in angle gauges can • Memory capacity, including date and time: up to 3000 measurements
also be used autonomously, without SmartTAC app • Offers possibility to program flow charts and sets of parameters: 25 and 25
• Unique ergonomic, user-oriented HAZET design of entire tool for professional use • 2 control functions: programmable torque control for angle
• The reduction in size and integration of the PCB into the tightening and angle control for torque tightening
main pipe results in dimensions that allow for the small • Menu locking against unintentional change, four-digit code is personally selected
torque wrench with built-in angle gauge from 1 Nm • Display of the software version with serial numbers,
• Protection rating IP 40 calibration date and service display / usage counter
Splash-proof display and membrane keyboard • Menu languages: German, English, French, Italian, Chinese
• USB-C port to directly charge battery when still in tool • Programming and evaluation software for laptop
• Including standard replaceable Li ion rechargeable battery, type 14650 and PC 7910-sTAC (at additional cost)
/ 3.7 Volt, can be charged directly on the tool via USB-C connector • SmartTAC app for Android and Apple iOS end devices
• Including 1 metre USB 3.1 / A-C cable for series 7000-2 sTAC (free download)
Functions: 7000 sTAC • The SmartTAC torque wrenches with built-in angle gauge of the 7000-2 sTAC
• Large, high-contrast illuminated, easily readable OLED series with Bluetooth interface have valid radio approval in all EU countries as
display, dimmable and 180° rotatable well as in Switzerland, Norway, China, India, South Korea, Mexico and Turkey
• Indication of the measuring values in 13 mm font size, and may be sold there.
including a rating of the screw-joint (OK / not OK) Other countries on request
• Display deviation in right and left torque: from ±1% / ±1 digit • For all other countries without radio licences, we offer the SmartTAC torque
• Display deviation in right and left rotation angle: ±1% / ±1° wrench with built-in angle gauge of the 7000-5 sTAC series without a Bluetooth
interface. These can be connected to a laptop and PC via a USB port and to
• Rotation angle range adding: 0 to 999° the optional programming and evaluation software. It is not possible to use the
• Torque tolerance for OK display (green): adjustable ±1 to 10% SmartTAC app for mobile devices due to the lack of a Bluetooth interface
• Rotation angle tolerance for OK display (green): adjustable 1 to 90° • With Bluetooth function
• Choice of torque measuring units: Nm, lbf ft, lbf in or kgf m • Tested in accordance with DIN EN ISO 6789-2:2017, VDI / VDE 2648, Sheet 2
• Lets you select or program the effective length for other insert tools from 0 to
250 m
(requirement for correct torque / rotation angle measurements)

YouTube Clip

B
320 Errors excepted Components and spare parts from page 500 to 509
