Torque technology

Torque testers and accessories

7900 E Torque tester ∙ electronic ∙ 1.5– 30 Nm

• Simple, intuitive operation J678 /
• Giant display with 17 mm large digits
• Traffic light function for evaluation of the measured value PLUS audible signal
• Easy entry of up to 15 different target values and the respective permissible tolerance in the range of ± 1 % to ± 15%
• Precision ± 1% (maximum display deviation)
• Digital readouts ∙ 3 measurement procedures
– Automatic click point detection (first peak ∙ click)
– Peak value measurement (final peak ∙ dial)
– Tracking measurement / display value (track)
• Triple signalling of the measurement result:
– Digit display in 17 mm font size
– Traffic light function for assessing the torque value
(yellow = too low ∙ green = OK ∙ red = too high)
– Audible signal
• Robust aluminium housing for workshop
use, surface powder-coated
• Large, high-contrast, luminous easy-to-
read LCD display with backlighting
• Self-sufficient operation possible via power bank (5 V ∙ 1 A)
• Maximum power consumption: 0.5 Wh ∙ energy efficiency level 6
• Rapid test function with auto reset, without target value
and tolerance specification, without evaluation
• Compatible with HAZET test software torque testing 7901E-
D, micro USB socket for power supply and data transmission
• Protection rating IP 40, splash-proof
display and membrane keyboard
• 10 adjustable menu languages:
German ∙ English ∙ French ∙ Spanish ∙ Italian ∙ Danish ∙
Finnish ∙ Swedish ∙ Norwegian ∙ Portuguese
• Included in delivery:
– USB power supply 90-264 volts AC at 47–63 HzOutput
voltage: 5 V ∙ 1000 mA ∙ USB 2.0 A socketIncludes
mains plug adapters for EU ∙ UK ∙ USA ∙ AUS
– Cable (2 m) USB 2.0 A plug – USB 2.0 micro B plug
– Calibration certificate and quick reference guide
(detailed operating instructions online for download)
Stable mounting on workbench

1 Drive K ! 4

• Calibrated measuring range in the clockwise direction of rotation
(measurements from 1 Nm are possible with a display deviation of approx. ± 2%)
• Fixed external hexagon socket ∙ size 10 mm including adapter J → 7 und J → 6
• Switchable torque display in Nm ∙ dNm ∙ cNm ∙ kgfm ∙ kgfcm ∙ gfm ∙ lbf.ft ∙ lbf.in ∙ ft.lb ∙ in.lb ∙ ozfin ∙ inoz
• Configurable selection of desired units
• Fixing material (not included in the scope of delivery): hexagon socket screws ISO 4762 – M6 – 8.8
• Gross weight including plastic case and accessories approx. 2.9 kg
1
7903 E g 10 = ⁄8″, j 6.3 = ⁄4″, j 10 = ⁄8″ 175 1.5 – 30 167425
3
3
• Calibrated measuring range in the clockwise direction of rotation
• Fixed internal square socket ∙ 12.5 = ⁄2˝
1
• Switchable torque display in Nm ∙ dNm ∙ kgfm ∙ kgfcm ∙ lbf.ft ∙ lbf.in ∙ ft.lb ∙ in.lb
• Configurable selection of desired units
• Fixing material (not included in the scope of delivery): hexagon socket screws ISO 4762 – M10 – 12.9
• Gross weight including plastic case and accessories approx. 3.9 kg
1
7901 E j 12.5 = ⁄2″ 138 10 – 350 140671
• Calibrated measuring range in the clockwise direction of rotation
• Fixed external hexagon socket ∙ size 27 mm
• Switchable torque display in Nm ∙ kgfm ∙ kgfcm ∙ lbf.ft ∙ lbf.in ∙ ft.lb ∙ in.lb
• Configurable selection of desired units
• Fixing material (not included in the scope of delivery): hexagon socket screws ISO 4762 – M10 – 12.9
• Gross weight including plastic case and accessories approx. 5.0 kg
7902 E g 27 mm 160 50 – 1100 150229
Components and spare parts from page 500 to 509 Errors excepted 329
