Hand tools Hand tools

4 Range of sockets 4 Range of sockets

1016 3/4″ Reversible ratchet head 1015 Sliding head ∙ with handle bar

Made in Germany 4 / Made in Germany 4
• Number of teeth: 32 (Opening angle 11.25°) • Handle bar HAZET 1014 and sliding head 1015-1
• Shank with bolt for locking pin retaining, • With locking
output with locking pin retaining pin retaining
• Surface: chrome-plated • Surface:
• DIN 3122, ISO 3315 chrome-plated,
polished
• DIN 3122

1 K 4 1 K è 4
1016 165 001941 1015/2 500 2 001927

Wear? – No problem! 1015 Sliding head
3 ⁄4 • HAZET tools are manufactured to the highest Made in Germany
quality. During long intensive loading there is a • For handle bar HAZET 1014 or 1014 P 4
certain level of wear even for high-quality tools.
• With locking pin retaining
• For this reason, there are spare parts and • Surface: chrome-plated, polished
replacement sets available for many of our tools.
• DIN 3122
Please also see our spare parts shop
www.hazet.de/ersatzteil-shop
Cost-saving – Sustainable – Resource-saving!
For long-term pleasure with your HAZET tools 1 K 4
1015-1 60 001910

1014 Handle bar
1016 Replacement set
Made in Germany
Made in Germany • For sliding head HAZET 1015-1 or ratchet head HAZET 1016
• With ball and locking pin retaining
• Surface: chrome-plated
• DIN 3122

1 K 4

1014 500 001897
1 4
1000 3/4″ Socket ∙ hexagon
• Replacement set for shift lever consisting of:
shift lever ∙ screws ∙ ball ∙ compression spring
For HAZET reversible ratchet 1016 ∙ 1016/2 Made in Germany c9 F
For HAZET torque wrench 5143-3CT ∙ 5145-3CT ∙ 6132-1CT ∙ 6143CT ∙ • Short design
6143-1CT ∙ 6144CT ∙ 6144-1CT ∙ 6145CT ∙ 6145-1CT ∙ 6146-1CT • With knurling
1016/6 001972 • With bolt for locking
• Replacement set for ratchet wheel 20 = ⁄4″ i consisting of: pin retaining
3
ratchet wheel ∙ pawl ∙ shift lever ∙ screws ∙ ball ∙ compression spring • Surface: chrome-plated,
For HAZET reversible ratchet 1016 ∙ 1016/2 polished
For HAZET torque wrench 5145-3CT ∙ 6132-1CT ∙ 6143CT ∙ 6143- • DIN 3124, ISO 2725-1
1CT ∙ 6144CT ∙ 6144-1CT ∙ 6145CT ∙ 6145-1CT ∙ 6146-1CT
1016/8 N 001989
1) Not according to DIN
3/4″ Reversible ratchet head ∙
1016 1 K G H c 4
with handle bar
1000-19 1) 52 28 33.2 14.5 000623
Made in Germany 4 / 1000-21 52 31 33.2 14 000647
• Number of teeth: 32 (Opening angle 11.25°) 1000-22 52 32 33.2 14 000654
• Shank with bolt for locking pin retaining, output with locking pin retaining 1000-24 52 34 36 16.5 000661
• Surface: chrome-plated, polished 1000-27 54 38 35 19.3 000678
1000-30 55 42 36 21.5 000692
1000-32 58 44.5 36 24 000708
1000-33 59 46 36 24.5 000715
1000-34 60 47.5 36 25.5 000722
1000-36 61.5 49.5 38 26.5 000746
1000-38 1) 65 52.5 39 29 000760
1000-41 68.5 55.5 39 32 000784
1000-42 1) 70 57.5 41 32 000791
1000-46 73 62 44 34 000807
1 K è 4 1000-50 1) 76 67 45 37.1 000814
45
73.5
000821
40.8
1000-55
82
1016/2 620 2 001965 1000-60 1) 88 80 45 44.9 000838
188 Errors excepted Components and spare parts from page 500 to 509
