Hand tools

5 Range of sockets

1100 Z 1″ Socket ∙ 12-point 1100 S 1″ Impact socket ∙ hexagon

Made in Germany r0 Made in Germany c0 /
• Short design • For high loading
• With knurling • Short design
• With bolt for locking pin retaining • With borehole for locking pin or safety spring
• Surface: chrome-plated, polished and groove for O-ring
• DIN 3124, ISO 2725-1 • Surface: phosphatized, oiled
• DIN 3129, ISO 2725-2

1) Not according to DIN
1 K G H c 4 1) Not according to DIN

1100 Z-32 1) 60 48 46 22 002511 1 K G H c 4
1100 Z-36 1) 67 52 48 28.5 002528
1100 Z-41 68 57 48 29.5 002535 1100 S-24 58 41.5 54 17 002207 1
1100 Z-46 72 62 48 32 002542 1100 S-27 60 45 54 19 002214
1100 Z-50 74 68 48 35 002559 1100 S-30 62 49 54 21 002221
1100 Z-55 78 74 48 36.5 002566 1100 S-32 1) 63 51.5 54 21 002238
1100 Z-60 83 80 48 40.5 002573 1100 S-33 63 52.5 54 21 002252
1100 Z-65 86 88 60 43.5 002580 1100 S-34 63 53.5 54 22 002269
1100 Z-70 89 96 60 46.5 002603 1100 S-36 67 56.5 54 23 002276
1100 Z-75 92 102 60 49.5 002610 1100 S-41 70 63 54 26 002290
1100 Z-80 94 108.5 60 52.5 002627 1100 S-46 76 69.5 54 28 002320
1100 S-50 82 74.5 54 30 002344
1100 S-55 87 81 54 32 002351
1158 1″→3/4″ Adapter 1100 S-60 91 87 54 34 002375

Made in Germany 40
• Drive with bolt for locking pin retaining, 1100 SLG 1″ Impact socket ∙ hexagon
output with locking pin retaining
• Surface: chrome-plated
• DIN 3123, ISO 3316 Made in Germany c0 /
3
• Reducer j input 25 = 1″ → i output 20 = /4″ • Long design
• With borehole for locking pin or safety spring and groove for O-ring
• Surface: phosphatized, oiled
• DIN 3129, ISO 2725-2

1 K 4
1158-2 70 003297

1121 1″→1″ Universal joint

Made in Germany 50 1 K G H c 4
• With hinge – for working in areas with restricted 1100 S Lg-24 110 41.5 54 17 002405
access and for getting around obstructive edges
• Drive with bolt for locking pin retaining, 1100 S Lg-27 110 45 54 19 002412
output with locking pin retaining 1100 S Lg-30 110 49 54 21 002429
• Surface: chrome-plated 1100 S Lg-32 110 51.5 54 21 002436
1100 S Lg-33 110 52.5 54 21 002443
1100 S Lg-36 110 56.5 54 23 002467
1100 S Lg-38 110 59 54 24 002474
1100 S Lg-41 110 63 54 26 002481
1100 S Lg-46 110 69.5 54 28 002498

1 K 4

1121 144 003273 1104 S 1″ Impact socket ∙ hexagon

1117 1″→1″ Extension Made in Germany c0 C/
• E.g. for deeply located wheel nuts and
bolts on commercial vehicles
Made in Germany 50 • Extra long design
• Drive with bolt for locking pin retaining, • With borehole for locking pin or safety
output with locking pin retaining spring and groove for O-ring
• Surface: chrome-plated, polished • Surface: phosphatized, oiled
• DIN 3123, ISO 3316 • DIN 3129, ISO 2725-2

1 K 4
1117- 8 200 003259 1 K G H c 4
1117-16 400 003242 1104 S-32 270 48.5 54 30.5 002665

Components and spare parts from page 500 to 509 Errors excepted 193
