Hand tools Hand tools

4 Range of sockets 4 Range of sockets

1058 Adapter 1000 S 3/4″ Impact socket ∙ hexagon

Made in Germany l 539 /
• With bolt for locking pin retaining Made in Germany c9 /
• Surface: chrome-plated • For high loading
• DIN 3123, ISO 3316 • Short design
• With borehole for locking pin or safety spring and groove for O-ring
• Surface: phosphatized, oiled
• DIN 3129, ISO 2725-2

1 K 4
1) Not according to DIN
• Amplifier j input 20 = /4″ → i output 25 = 1″
3
• Locking pin retaining 1 K G H c 4
3 ⁄4 1058-1 60.6 002061 1000 S-19 1) 48 32 44 13 001231
• Reducer j input 20 = /4″ → i output 12.5 = /2″ 1000 S-22 50 36.5 44 16 001248
1
3
• Locking ball 1000 S-24 50 39.5 44 17 001255
• Replaceable square 1058-02A 1000 S-27 51 43.5 44 19 001262
1058-2 52.3 002078 1000 S-28 1) 54 45 44 19 001279
• Insert square for HAZET adapter 1058-2 1000 S-30 54 47.4 44 21 001293
1058-02 A 28 233557 1000 S-32 54 49.9 44 21 001309
1000 S-33 1) 54 51.5 44 16 001316
1000 S-34 54 52.4 44 16.8 001323
1021 3/4″→3/4″ Universal joint 1000 S-36 57 54.9 44 23 001330
Made in Germany 49
• With hinge – for working in areas 1000 SLG 3/4″ Impact socket ∙ hexagon
with restricted access and for getting
around obstructive edges
• Drive with bolt for locking pin retaining, Made in Germany
output with locking pin retaining • Long design c9 /
• Surface: chrome-plated • With borehole for locking pin or safety spring and groove for O-ring
• DIN 3123, ISO 3316
• Surface: phosphatized, oiled
• DIN 3129, ISO 2725-2

1 K 4
1021 105 002054
1) Not according to DIN
1017 3/4″→3/4″ Extension
1 K G H c 4
Made in Germany 49 1000 S Lg-24 100 39.5 44 17 001392
• Drive with bolt for locking pin 1000 S Lg-27 100 43.5 44 19 001408
retaining, output with locking pin retaining 1000 S Lg-30 100 47.5 44 21 001422
• Surface: chrome-plated, polished
1000 S Lg-32 100 50 44 21 001439
1000 S Lg-33 1) 100 51.5 44 21 001446
1000 S Lg-36 100 55 44 23 001460

1004 S 3/4″ Impact socket ∙ hexagon
1) DIN 3123, ISO 3316
1 K 4
Made in Germany c9 C/
1017-3 75 001996 • E.g. for deeply located wheel nuts and
1017-8 1) 200 002016 bolts on commercial vehicles
• Extra long design
• With borehole for locking pin or safety
1018 3/4″→3/4″ Extension spring and groove for O-ring
• Surface: phosphatized, oiled
Made in Germany 49 • DIN 3129, ISO 2725-2
• Drive with bolt for locking pin
retaining, output with locking pin retaining
• DIN 3123, ISO 3316

1) Not according to DIN
1 K G H c 4
1 K 4 1004 S-32 400 48 44 32 055784
1018 400 002030 1004 S-33 1) 400 48 44 32 055791
190 Errors excepted Components and spare parts from page 500 to 509
