Hand tools

4 Range of sockets

1000 Z 3/4″ Socket ∙ 12-point 2784 3/4″ Brake calliper screwdriver socket

Made in Germany r9 F Made in Germany b9 R
• Short design • Drive allows transmission of high separation forces
• With knurling
• With bolt for locking • Controlled screw tightening with the torque value required by the manufacturer
pin retaining (follow manufacturer‘s instructions) e.g. with torque wrench HAZET 6144-1CT
• Surface: chrome-plated, • With knurling
polished • With bolt for locking pin retaining
• DIN 3124, ISO 2725-1
1) Not according to DIN
1 K G H c 4
1000 Z-22 52 32 33.2 13.5 001507
1000 Z-24 52 34 36 16 001521
1000 Z-27 54 38 35 18.8 001552
1000 Z-30 55 42 36 21 001583
1000 Z-32 58 44.5 36 23.4 001590 1 3 ⁄4
1000 Z-34 60 47.5 36 24.8 001613 S M N F 4
1000 Z-35 1) 61.5 48.5 35.5 25.8 001620 2784-14 14 60 112 33.2 155583
1000 Z-36 61.5 49.5 36 25.7 001637
1000 Z-38 1) 65 52.5 38 28.3 001644
1000 Z-41 68.5 55.5 39 31.2 001651
1000 Z-46 73 62 44 34 001675 TiN coating
1000 Z-50 76 67 45 37.1 001699
1000 Z-55 82 73.5 45 40.8 001712
Why choose TiN (Titanium Nitride) coating?
• A special coating process for extremely hard TiN coating guarantees high
1000 AZ 3/4″ Socket ∙ 12-point adhesive strength and wear resistance of the coating
• Particularly suitable for continuous load, e. g. for industrial applications in
industry and trade
Made in Germany r9 • Higher wear protection guarantees a longer lifetime
• Short design
• American dimensions • Perfect fitting accuracy due to optimum coating thickness
• With knurling • Optimized corrosion protection
• With bolt for locking
pin retaining
• Surface: chrome-plated,
polished
TIN coated
screwdriver sockets
1 K G H c 4
1000 AZ-7/8 52 32 33.2 13.5 001170
1000 AZ-15/16 52 34 36 16.9 001132
1000 AZ-1 52 36.5 33.2 16.9 000999
1000 AZ-1.1/16 54 38 35 18.8 001002
1000 AZ-1.1/8 55 40 36 20.8 001033
1000 AZ-1.3/16 55 42 36 21 001064
1000 AZ-1.1/4 58 44.5 36 23.4 001026 Wear
1000 AZ-1.5/16 59 46 36 23.9 001095 Conventional
coatings
1000 AZ-1.3/8 61.5 48.5 36 25.8 001088 HAZET TiN
1000 AZ-1.7/16 63 50 36 27.2 001118 coatings
1000 AZ-1.1/2 65 52.5 38 28.6 001019
1000 AZ-1.5/8 68.5 55.5 39 31.2 001101
1000 AZ-1.3/4 72 60 41 33.6 001071
1000 AZ-1.13/16 73 62 44 34 001057
1000 AZ-1.7/8 73 64 45 35 001125
1000 AZ-2 78 68 45 38.7 001149 t (time)

1010 3/4″ Screwdriver socket 1012 3/4″ Screwdriver socket ∙ h

Made in Germany b9 Made in Germany l N9
• Short design • Short design
• With knurling • With knurling
• With bolt for locking • With bolt for locking
pin retaining pin retaining
• Surface: chrome-plated, • Surface: TIN coated
tips burnished
• DIN 7422
1 Ä M N F r 4
1 S M N F 4 1012-T 60 T60 28 80 33.2 13.25 087488
1010-14 14 16.7 54.5 36 001842 1012-T 70 T70 28 80 33.2 15.54 087495
1010-17 17 19.7 54.5 36 001859 1012-T 80 T80 28 80 33.2 17.59 087501
1010-19 19 21.7 56.5 36 001866 1012-T 90 T90 28 80 33.2 19.95 087518
1010-22 22 24.7 56.5 36 001873 1012-T 100 T100 28 80 33.2 22.15 087525

Components and spare parts from page 500 to 509 Errors excepted 189
