Page 128 - HAZET哈蔡特2024英文样本

Hand tools Hand tools

Wrenches Wrenches

606 Ratcheting combination wrench 606 Ratcheting combination wrench set

• Operation of screw connections in areas with restricted % C %/
access, ratchet function enables continuous working

• Long, slim design 1 L x W x H 4
• Shank with sturdy HAZET double‑T‑profile mm è
• Box‑end wrench with reversible ratchet 606 • %
• Fine-tooth, 72 teeth ∙ Operating angle 5° 8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19
Ä 8 and 9 mm: 60 teeth ∙ Operating angle 6°
• Box-end side 13° offset 606 N/12 355 x 235 x 65 12 197378
• Head set at: 15° 606 • %
• Surface: chrome-plated 8 • 10 • 12 • 13 • 17 • 19
606 N/6 355 x 235 x 65 6 196937

• Safety-Insert-System, 2-component soft foam insert. %S/
Insert also suitable for HAZET Assistent

1 K 2 3 6 7 4
606- 8 129.9 6.8 4.9 16.8 16.7 100941
606- 9 143 7.2 5.2 18.5 18.8 100958
606-10 154.5 7.6 5.6 20.1 20.9 100965
606-11 168.6 8 6 21.7 23 100972
606-12 180.3 8.5 6.4 22.9 25.9 100989
606-13 193.2 8.9 6.7 24.9 27.2 100996 163-97/6 163-515/16 163-366/18
606-14 204.6 9.3 7.1 27.2 29.3 101009
606-15 218 9.7 7.4 28.6 31.3 101016
606-16 230.2 10.2 7.7 30.1 33.4 101023 1 L x W è 4
606-17 242.2 10.6 8.1 32 35.5 101030 mm
606-18 255 11 8.5 32.9 37.6 101047 606 • %
606-19 268.3 11.5 9.1 34.1 39.7 101054 8 • 10 • 12 • 13 • 17 • 19
606-21 291.5 13.3 12 44.3 48.3 151233 163-97/6 342 x 172 6 145683
606-22 291.5 13.3 12 44.3 48.3 151028
606-24 333.1 14.8 12.5 51.2 53.5 151011 For HAZET i with drawer depth of 398 mm:
173 ∙ 179 ∙ 179N ∙ 179NX ∙ 179W ∙ 179NW ∙ 179BIG-1 ∙ 179XL ∙
606-27 359.2 15.8 14.7 54.9 60.2 151004 179NXL ∙ 179XXL ∙ 179NXXL ∙ 179AXXL ∙ 179TXXL ∙ 180
606-30 402.5 17.3 15.2 60.8 67 150991
606-32 425.8 17.8 15.7 64.2 71 150984 606 • %
8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 606/4 SPC
163-515/16 392 x 172 16 218721
606 Ratcheting combination wrench set 606 • %
8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 21 • 22 • 24 • 27 • 30 • 32
• Surface: chrome-plated % 163-366/18 519 x 342 18 196920

610 N Double box-end wrench

Made in Germany %
• Ergonomically shaped, heads offset
• Shank with sturdy HAZET
double-T-profile
• Surface: chrome-plated,
head polished
• DIN 837 form B, ISO 10103
1 è 4

606 • %
21 • 22 • 24 • 27 • 30 • 32
606/6-1 6 175178
1) Not according to DIN
• Plastic box 165-L (1/3) %/ 1 K 1 6 7 4
• Safety-Insert-System, 2-component soft foam insert. 610 N- 6 x 7
Insert also suitable for HAZET Assistent 97.9 4.5 9.6 11 024940
• Surface: chrome-plated 610 N- 8 x 9 113.3 5.2 12.3 13.6 024957
610 N-10 x 11 125.3 6 14.9 16.2 024735
610 N-12 x 13 139 6.2 17.8 18.9 024742
610 N-14 x 15 154.5 7 20.2 21.5 024780
610 N-16 x 17 170 7.5 22.7 24.1 024797
610 N-18 x 19 188.6 8.5 26 27 024827
610 N-20 x 22 1) 208.8 9 28.4 30.4 024834
610 N-21 x 22 1) 232.3 10 29.8 32.2 024841
610 N-21 x 23 1) 232.3 10 29.8 32.7 024858
610 N-24 x 26 1) 254 11 34.1 37 024872
610 N-25 x 28 1) 280.1 11.5 35.5 39.8 024896
610 N-27 x 32 308.7 13 38.9 45.4 024902
610 N-30 x 32 324.1 13 42.7 45.4 024919
B 610 N-30 x 34 326.7 14 42.7 48 024926
126 Errors excepted Components and spare parts from page 500 to 509
