Hand tools

Wrenches

600 LG Combination wrench ∙ extra long 603 Combination wrench

Made in Germany % C $%
• Loading capacity at least twice as high as DIN
• At least 25% longer than comparable standard 1 K 2 3 6 7 4
wrenches – for greater power transmission 603-24 270 13.5 8.5 35.1 51 023844
• Better accessibility with low‑lying screw connections
• Shank with extra sturdy double‑T‑profile 603-27 305 15 9.3 38.5 57.3 023868
slim design 603-30 340 16 10 42.7 63.4 050260
• Surface: chrome-plated 603-32 360 17 10.5 45.5 67.2 023882

603 Combination wrench set

Made in Germany %
• Surface: chrome-plated
• DIN 3113 form B, ISO 3318, ISO 7738,
In accordance with DIN EN 3709

1 è 4
YouTube Clip
603 • r
7 • 8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 21 • 22 • 24 • 27
1 è 4 603/17 N 17 024063

600 LG • %
10 • 13 • 14 • 17 • 19 • 24 • 27 • 32 Made in Germany %/
600 LG/8 8 199938 • Surface: chrome-plated
• DIN 3113 form B, ISO 3318, ISO 7738,
600 LG • % In accordance with DIN EN 3709
10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19
600 LG/10 10 218424
600 LG • %
10 • 11 • 12 • 13 • 14 • 17 • 19 • 22 • 24 • 27 • 30 • 32
600 LG/12 12 202492
600 LG • %
10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 21 • 22 • 24
600 LG/13 13 218417

603 Combination wrench
Made in Germany $%
• Box-end head 10° offset
• Head setting: 15° 1 è 4
• Surface: chrome-plated
• DIN 3113 form B, ISO • In clip for wall fixation
3318, ISO 7738, In
accordance with DIN EN 3709 603 • r
6 • 7 • 8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 21 • 22 • 24
603/17 H 17 024049
1) Box‑end head with hexagon Made in Germany
2) Not according to DIN • Safety-Insert-System, %S/
1 K 2 3 6 7 4 2-component soft foam insert.
Insert also suitable for HAZET Assistent
603-5.5 1) 2) 90 4.7 3.7 9.8 14.1 023929 • DIN 3113 form B, ISO 3318, ISO 7738,
603-6 1) 100 5.1 4 10.5 14.9 023950 In accordance with DIN EN 3709
603-7 1) 110 5.5 4.3 12.2 16.8 023981
603-8 1) 120 5.9 4.5 13.1 18.3 024018
603-9 1) 130 6.3 4.5 14.6 21 024025
603-10 137 6.7 5 15.6 23 023691
603-11 145 7.1 5.2 17.1 25 023714
603-12 152 7.6 5.4 18.4 26.8 023721
603-13 160 8 5.6 19.9 28.8 023738
603-14 170 8.5 5.8 21.4 30.7 023752
603-15 180 9 6 22.5 32.6 023769
603-16 190 9.5 6.2 24 34.6 023776
603-17 200 10 6.4 25.5 36.5 023783
603-18 210 10.5 6.7 26.9 38.6 023790 1 L x W è 4
603-19 220 11 7 28.4 40.6 023806 mm
603-21 240 12 7.6 30.7 44.8 023820 603 • r
603-22 250 12.5 7.9 32.2 46.8 023837 6 • 7 • 8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 • 16 • 17 • 18 • 19 • 21 • 22 • 24 • 27
B 163-99/18 344 x 342 18 145706

Components and spare parts from page 500 to 509 Errors excepted 125
