Mil-I-81969 Cross Reference Chart Insertion & Removal Tool Illustrations

INSERTION TOOLS ILL 2 IdenTIFICATIOn InFORMATIOn

Straight (ILL. 1) and joggled tools (ILL. 2) hold contact and wire in line with
center or side of the tool handle. Tool sizes are “0” to “24” gage. Handles are
color coded aluminum. Tools range from 4 1/2” to 6” long with replaceable tips.

ILL 1

FRONT REMOvAL, REAR INSERTION TOOLS FRONT RELEASE

Both front removal (Ill. 3) and rear insertion (Ill. 4) Military Front release connecters are easily serviced with these
Standard tools offer a convenient and practical approach to military spec removal tools. Handles are color coded for
servicing the MIL-C-81511, Series 1 & 2 connectors. Tools are contact size. Replaceable tips are available.
color coded for contact size with half-inch hex metal handles.
ReF: MIL-C-005015, MIL-C-26482, MIL-C-26500,
and MIL-C-26636 Connectors.

ILL 3

ILL 6

ILL 4

ILL 5
