Insertion and Removal Tool Selection Charts Listed by Contact Manufacturer

LISTed By COnTACT MAnUFACTUReR J-1276-1 ATB 3062-2 I & R R R R R R yHMM-22-1 Pins, plastic tip, - 29 2 2 2 12 yHMM SERIES
GAGE
USAGE/
I/R
ILL.
TOOL IDENTIFICATION NUMBERS
R/F
CONNECTOR
DESCRIPTION
BURNDY/FCI
ASTRO TOOL #
yHMM
recommended ATB 3062-2
J-1276-3
yHMM-22-1 Pins, plastic tip
I & R
yHMM
29
yHMM-22-1 Pins, plastic tip (Longer Handle)
I & R
ATB 3062-4
J-1276-4
I
ATA 1144 or
MIL-C-26500, Metal Interchangeable Probe Tool
26
HyFen
RTM-12-5
12
HyFen
AT 1000-12
I
2
MIL-C-26500, Metal Tool, Joggled
RTM-12-8
ATA 1101
HyFen
MIL-C-26482, Metal Interchangeable Probe Tool
26
16
RTM-16-2V
JT
MIL-C-38999, Metal Tool, Tweezer
10
16
ATBX 1108
RTM-16-4 ATBX 1157 I I I R R R MIL-C-38999, Metal Tool, Joggled 10 12 JT
RTM-20-5 ATB 1064 or I R MIL-C-26482, 26500, 26636, Metal Interchangeable Probe Tool 26 20 HyFen
ATB 1067 or I R Modified version of ATB 1064, Long Tip, Metal Interchangeable 26 20 HyFen
Probe Tool
ATB 1068 I R Modified version of ATB 1067, Joggled 2 20 HyFen
RTM-20-5PI ATB 1067-R I R Tip to fit Burndy RTM-20-5 25 20 HyFen
RTM-20-17 ATBX 1072 I R MIL-C-38999, Metal Tool, Tweezer 10 20 JT
RTM-22-1 ATBX 1058 I R MIL-C-38999, Metal Tool, Tweezer 10 22 JT
RTM-24-3 ATBX 1053 I R MIL-C-38999, Metal Tool, Tweezer 10 24 JT
RTM-20-16 AT1000-20 I R Metal Tool, Joggled 2 20
RX-8-1 ATH 2202 R F Metal Tool, Coaxial 6 8
RX-12-7 AT 2012 R F MIL-C-26636, 26482 6 12 HyFen
RX-12-9 ATBX 2155 R R MIL-C-38999 10 12 JT
RX-16-7-V1 ATB 2114 R F Modified MS24256R-16, Revision e 6 16 HyFen
RX-16-7-V2 ATB 2114 R F Modified MS24256R-16, Revision e 6 16 HyFen
RX-16-8 AT 2016 R F MIL-C-26482 6 16 HyFen
RX-16-9 ATBX 2103 R R MIL-C-38999 10 16 JT
RX-20-10 ATB 2088 R F MIL-C-26500, 26636, Metal Spring-Loaded Probe Tool 8 20 HyFen
RX-20-24 AT 2020 R F MIL-C-26482 6 20 HyFen
RX-20-24V3 ATB 2080 R F MIL-C-26482 (MS24256R-20, Revision e) Modified 6 20 HyFen
RX-20-24V5 ATB 2080 R F MIL-C-26482 (MS24256R-20, Revision e) Modified 6 20 HyFen
RX-20-36 ATBX 2070 R R MIL-C-38999 10 20 JT
RX-22-1 ATBX 2057 R R MIL-C-38999 10 22 JT
RX-24-3 ATBX 2046 R R MIL-C-38999 10 22d JT
ATB 1035 I R Unwired Contact 28-91-S-9000 1 22
ATB 1043 I R Unwired Contact 39029/18-20-20 1 20
ATB 1044 I R Unwired Contact 2749420 1 20
ATB 1066 I R Unwired Contact 0641-1-1631 1 16
TOOL IDENTIFICATION NUMBERS I/R R/F USAGE/ ILL. GAGE CONNECTOR
DESCRIPTION SERIES
COLLINS RADIO ASTRO TOOL #
372-8091-010 ATC 2026 R F Tuning Fork Contacts 11 --
372-8091-060 ATC 1032 I R Tweezer, Filter Pins 30 --

58
