Insertion and Removal Tool Selection Charts Listed by Contact Manufacturer

TOOL IDENTIFICATION NUMBERS I/R R/F USAGE/ ILL. GAGE CONNECTOR TOOL IDENTIFICATION NUMBERS I/R R/F USAGE/ ILL. GAGE CONNECTOR
DESCRIPTION SERIES DESCRIPTION SERIES
AMPHENOL/MATRIX ASTRO TOOL # BOEING ASTRO TOOL #
90-0001-022 ATM 1046 I R Mini-Mate 23 22 ATBO 1053 I R Special Plier Repair Tool for m39029/11-22 & 12-22 13 22
ATM 1046-135 I R Modified version of ATM 1046, 45 degree angle 23 22 ATBO 1054 I R Modified version of ATC 1054, 1.1 Long Tip 2 22
90-0002-022 ATM 2052 R F Mini-Mate, Metal Spring-Loaded Probe Tool 8 22 (CIT dPXMA22-1) IdenTIFICATIOn InFORMATIOn
258-6018-16 ATR 2112 R R Metal Tool, Tweezer 10 16 ATBO 1070 I R Contact BACC47dT&S - 20
258-6019-16 ATR 1107 I R Metal Tool, Joggled 2 16 ATBO 1075 I R nAS 1599 Connector - 20
259-6002-20 ATR 2080 R R Metal Tool, Tweezer 10 20 ATBO 1075-L I R Modified version of ATBO 1075, Longer Tip - 20
5000-026-22 ATRX 2052 R R Metal Tool, Tweezer 10 22 ATBO 1081 I R Contact BACC47dT&S - 16
6500-001-20 ATR 1080 and I R Metal Tool, Joggled 2 20 ATBO 1081-L I R Modified version of ATBO 1081, Longer Tip - 16
ATR 2080 R R Metal Tool, Tweezer 10 20 ATBO 1082 I R nAS 1599 Connector 2 20
6500-001-16 ATR 1107 and I R Metal Tool, Joggled 2 16 ATBO 1105 I R Metal Tool, Tweezer Tool 10 16
ATR 2112 R R Metal Tool, Tweezer 10 16 ST 2342A-T1 ATBO 1107 I R Metal Tool, Joggled “Horses Head” 2 16
6500-001-12 ATR 1160 and I R Metal Tool, Joggled 2 12 ATBO 1108 I R Arbor Press 2 16
ATR 2160 R R Metal Tool, Tweezer 10 12 ATBO 1108-90 I R Modified version of ATBO 1108, 90 degree Angle 1 16
6500-018-0 ATC 2565 R R 5015 Connector, Rear Release 19 0 ST 2342A-T5 ATBO 1154 I R Metal Tool, Joggled “Horses Head” 2 12
6500-018-4 ATC 2426 R R 5015 Connector, Rear Release 19 4 ATBO 2054 R R Special Boeing Tool (CeT dPXMA22) 2 22
6500-018-8 ATC 2281 R R 5015 Connector, Rear Release 19 8 ATBO 2073 R R Hypertronics Connector, Metal Spring-Loaded Probe Tool 8 20 k65
6500-028-12 ATC 2157 R R Modified version of ATR 2160, straight 10 12 ATBO 2082 R R nAS 1599 -- Oversize Wire 2 20
6500-028-16 ATC 2106 R R Modified version of ATR 2112, straight 10 16 ST 2342PB ATBO 2342-PB I R Handle inserts wire wrap contacts - -
6500-028-20 ATC 2079 R R Modified version of ATR 2080, straight 10 20 ATBO 2342-PB (Replaceable tips for basic tool listed below)
6500-029-12 ATR 2160 R R PLASTIC Tweezer, 70 degree angle 10 12 /1 I R Original Tip - 22
6500-029-16 ATR 2112-L R R PLASTIC Tweezer, 70 degree angle 10 16 /2 I R Modified .050 I.d. - 22
6500-029-20 ATR 2080 R R PLASTIC Tweezer, 70 degree angle 10 20 /3 I R Modified ATC 1054 Tip - 22
6500-030-12 ATgH 1160 I R Straight In-Line, PLASTIC 1 12 /4 I R Modified to .062 I.d. - 22
6500-030-16 ATgH 1112 I R Straight In-Line, PLASTIC 23 16
6500-030-20 ATgH 1079 I R Straight In-Line, PLASTIC 23 20
6500-045-20 ATC 1071 and I R Metal Comparable for Hydraulic Research 23 20
ATC 2076 R R Metal Comparable for Hydraulic Research 10 20
ATM 1050 I R Special Close 90 degree Bend 23 22

CHART ABBREVIATIONS

I/R Insertion or Removal designation column R Rear Release
I Insertion Tool F Front Release
R Removal Tool R & F Rear and Front Release
I & R Insertion & Removal Tool ILL Illustration reference number
R/F Rear or Front Release designation column GA gage designation
NAATT not Available At This Time
