附件
套筒
动力套筒1/4" 方寸驱动头 零件型号 螺母尺寸 螺栓深度 零件型号 螺母尺寸 螺栓深度
零件型号 螺母尺寸 螺栓深度 英寸/毫米 英寸（毫米） 英寸/毫米 英寸（毫米）
英寸/毫米 英寸（毫米） S62M15L 15 mm 0.31 (8) S63M17 17mm 0.39 (10)
标准-内六角 球形-内六角 S63M18 18mm 0.51 (13)
S62H316 3/16" 0.2 (5) S62H14U 1/4" 0.24 (6) S63M19 19mm 0.51 (13)
S62H732 7/32" 0.2 (5) S62H516U 5/16" 0.24 (6) S63M20 20mm 0.51 (13)
S62H14 1/4" 0.2 (5) S62H38U 3/8" 0.31 (8) S63M21 21mm 0.51 (13)
S62H932 9/32" 0.28 (7) S62H716U 7/16" 0.31 (8) S63M22 22mm 0.51 (13)
S62H516 5/16" 0.28 (7) S62H12U 1/2" 0.31 (8) 深-内六角
S62H1132 11/32" 0.28 (7) S62H916U 9/16" 0.31 (8) S63H516L 5/16" 0.47 (12)
S62H38 3/8" 0.31 (8) S62M5U 5mm 0.24 (6) S63H38L 3/8" 0.55 (14)
S62H716 7/16" 0.31 (8) S62M55U 5.5mm 0.24 (6) S63H716L 7/16" 0.67 (17)
S62H12 1/2" 0.31 (8) S62M6U 6mm 0.24 (6) S63H12L 1/2" 0.67 (17)
S62H916 9/16" 0.31 (8) S62M7U 7mm 0.24 (6) S63H916L 9/16" 0.67 (17)
S62M4 4mm 0.2 (5) S62M8U 8mm 0.31 (8) S63H58L 5/8" 0.67 (17)
S62M45 4.5mm 0.2 (5) S62M9U 9mm 0.31 (8) S63H1116L 11/16" 0.67 (17)
S62M10U 10mm 0.31 (8) S63H34L 3/4" 0.75 (19)
S62M5 5mm 0.91 (23)
S62M55 5.5mm 0.91 (23) S62M11U 11mm 0.31 (8) S63H1316L 13/16" 0.75 (19)
S62M12U 12mm 0.31 (8) S63H78L 7/8" 0.75 (19)
S62M6 6mm 0.28 (7)
S62M7 7mm 0.28 (7) S62M13U 13mm 0.31 (8) S63H1516L 15/16" 0.83 (21)
S62M8 8mm 0.28 (7) S62M14U 14mm 0.31 (8) S63H1L 1mm 0.83 (21)
S62M9 9mm 0.28 (7) S62M15U 15mm 0.31 (8) S63M7L 7mm 0.43 (11)
S62M10 10mm 0.28 (7) S63M8L 8mm 0.47 (12)
S62M11 11mm 0.31 (8) S63M9L 9mm 0.55 (14)
S62M12 12mm 0.31 (8) 动力套筒3/8" 方寸驱动头 S63M10L 10mm 0.55 (14)
S62M13 13mm 0.31 (8) S63M11L 11mm 0.67 (17)
S62M14 14mm 0.31 (8) 零件型号 螺母尺寸 螺栓深度 S63M12L 12mm 0.67 (17)
S62M15 15mm 0.31 (8) 英寸/毫米 英寸（毫米） S63M13L 13mm 0.67 (17)
深-内六角 标准-内六角 S63M14L 14mm 0.67 (17)
S63H14 1/4" 0.16 (4) S63M15L 15mm 0.75 (19)
S62H316L 3/16" 0.2 (5)
S63H516 5/16" 0.28 (7) S63M16L 16mm 0.75 (19)
S62H732L 7/32" 0.2 (5)
S63H38 3/8" 0.28 (7) S63M17L 17mm 0.75 (19)
S62H14L 1/4" 0.2 (5)
S63H716 7/16" 0.28 (7) S63M18L 18mm 0.75 (19)
S62H932L 9/32" 0.28 (7)
S63H12 1/2" 0.28 (7) S63M19L 19mm 0.83 (21)
S62H516L 5/16" 0.28 (7)
S63H916 9/16" 0.28 (7) S63M20L 20mm 0.83 (21)
S62H1132L 11/32" 0.28 (7)
S62H38L 3/8" 0.31 (8) S63H58 5/8" 0.39 (10) S63M21L 21mm 0.83 (21)
S63H1116 11/16" 0.39 (10) S63M22L 22mm 0.83 (21)
S62H716L 7/16" 0.31 (8)
S62H12L 1/2" 0.31 (8) S63H34 3/4" 0.39 (10) 球形-内六角
S63H1316 13/16" 0.51 (13) S63H516U 5/16" 0.47 (12)
S62H916L 9/16" 0.31 (8)
S62M4L 4mm 0.2 (5) S63H78 7/8" 0.51 (13) S63H38U 3/8" 0.47 (12)
S63H1516 15/16" 0.51 (13) S63H716U 7/16" 0.47 (12)
S62M45L 4.5mm 0.2 (5)
S62M5L 5mm 0.2 (5) S63H1 1mm 0.51 (13) S63H12U 1/2" 0.47 (12)
S63M6 6mm 0.16 (4) S63H916U 9/16" 0.47 (12)
S62M55L 5.5mm 0.2 (5)
S62M6L 6mm 0.28 (7) S63M7 7mm 0.28 (7) S63H58U 5/8" 0.47 (12)
S63M8 8mm 0.28 (7) S63H1116U 11/16" 0.47 (12)
S62M7L 7mm 0.28 (7)
S63M9 9mm 0.28 (7) S63H34U 3/4" 0.47 (12)
S62M8L 8mm 0.28 (7)
S63M10 10mm 0.28 (7) S63H1316U 13/16" 0.47 (12)
S62M9L 9mm 0.28 (7)
S63M11 11mm 0.28 (7) S63H78U 7/8" 0.47 (12)
S62M10L 10mm 0.28 (7)
S62M11L 11mm 0.31 (8) S63M12 12mm 0.28 (7) S63H1516U 15/16" 0.47 (12)
S63M13 13mm 0.28 (7) S63H1U 1mm 0.47 (12)
S62M12L 12mm 0.31 (8)
S62M13L 13mm 0.31 (8) S63M14 14mm 0.28 (7) S63M8U 8mm 0.47 (12)
S63M15 15mm 0.39 (10) S63M9U 9mm 0.47 (12)
S62M14L 14mm 0.31 (8)
S63M16 16mm 0.39 (10)
