附件

套筒

零件型号 螺母尺寸 螺栓深度 零件型号 螺母尺寸 螺栓深度 零件型号 螺母尺寸 螺栓深度
英寸/毫米 英寸（毫米） 英寸/毫米 英寸（毫米） 英寸/毫米 英寸（毫米）
S68M29U 29mm 0.67 (17) S612H2-78 2-7/8" 1.93 (49) S612M95 95mm 2.4 (61)
S68M30U 30mm 0.67 (17) S612H2-1516 2-15/16" 1.93 (49) S612M100 100mm 2.56 (65)
S68M32U 32mm 0.87 (22) S612H3 3" 1.93 (49) S612M105 105mm 2.68 (68)
S68M33U 33mm 0.87 (22) S612H3-116 3-1/16" 2.09 (53) S612M110 110mm 2.83 (72)
S68M34U 34mm 0.87 (22) S612H3-18 3-1/8" 2.09 (53) S612M115 115mm 3.03 (77)
S68M35U 35mm 0.87 (22) S612H3-316 3-3/16" 2.09 (53) S612M120 120mm 3.03 (77)
S68M36U 36mm 0.87 (22) S612H3-14 3-1/4" 2.09 (53) S612M125 125mm 3.03 (77)
S68M38U 38mm 0.98 (25) S612H3-516 3-5/16" 2.2 (56) 深-内六角
S68M41U 41mm 0.98 (25) S612H3-38 3-3/8" 2.2 (56) S612H1-58L 1-5/8" 1.1 (28)
S68M42U 42mm 0.98 (25) S612H3-716 3-7/16" 2.2 (56) S612H1-1116L 1-11/16" 1.1 (28)
S68M43U 43mm 0.98 (25) S612H3-12 3-1/2" 2.32 (59) S612H1-34L 1-3/4" 1.18 (30)
S68M44U 44mm 0.98 (25) S612H3-916 3-9/16" 2.32 (59) S612H1-1316L 1-13/16" 1.18 (30)
S68M45U 45mm 1.06 (27) S612H3-58 3-5/8" 2.32 (59) S612H1-78L 1-7/8" 1.26 (32)
S68M46U 46mm 1.06 (27) S612H3-1116 3-11/16" 2.4 (61) S612H1-1516L 1-15/16" 1.26 (32)
S68M47U 47mm 1.06 (27) S612H3-34 3-3/4" 2.4 (61) S612H2L 2" 1.34 (34)
S68M48U 48mm 1.06 (27) S612H3-1316 3-13/16" 2.56 (65) S612H2-116L 2-1/16" 1.34 (34)
S68M50U 50mm 1.06 (27) S612H3-78 3-7/8" 2.56 (65) S612H2-18L 2-1/8" 1.46 (37)
S612H3-1516 3-15/16" 2.56 (65) S612H2-316L 2-3/16" 1.46 (37)
S612H4 4" 2.56 (65) S612H2-14L 2-1/4" 1.54 (39)
动力套筒1-1/2" 方寸驱动头 S612H4-116 4-1/16" 2.68 (68) S612H2-516L 2-5/16" 1.54 (39)

零件型号 螺母尺寸 螺栓深度 S612H4-18 4-1/8" 2.68 (68) S612H2-38L 2-3/8" 1.54 (39)
英寸/毫米 英寸（毫米） S612H4-316 4-3/16" 2.68 (68) S612H2-716L 2-7/16" 1.65 (42)
S612H4-14 4-1/4" 2.83 (72) S612H2-12L 2-1/2" 1.65 (42)
标准-内六角
S612H4-516 4-5/16" 2.83 (72) S612H2-916L 2-9/16" 1.65 (42)
S612H1-316 1-3/16" 0.83 (21)
S612H4-38 4-3/8" 2.83 (72) S612H2-58L 2-5/8" 1.81 (46)
S612H1-14 1-1/4" 0.87 (22)
S612H1-516 1-5/16" 0.87 (22) S612H4-716 4-7/16" 2.83 (72) S612H2-1116L 2-11/16" 1.81 (46)
S612H4-12 4-1/2" 3.03 (77) S612H2-34L 2-3/4" 1.81 (46)
S612H1-38 1-3//8" 0.87 (22)
S612H1-716 1-7/16" 0.94 (24) S612H4-58 4-5/8" 3.03 (77) S612H2-1316L 2-13/16" 1.93 (49)
S612H4-34 4-3/4" 3.03 (77) S612H2-78L 2-7/8" 1.93 (49)
S612H1-12 1-1/2" 1.02 (26)
S612M30 30mm 0.83 (21) S612H2-1516L 2-15/16" 1.93 (49)
S612H1-916 1-9/16" 1.1 (28)
S612M32 32mm 0.87 (22) S612H3L 3" 1.93 (49)
S612H1-58 1-5/8" 1.1 (28)
S612M35 35mm 0.87 (22) S612H3-116L 3-1/16" 2.09 (53)
S612H1-1116 1-11/16" 1.1 (28)
S612H1-34 1-3/4" 1.18 (30) S612M36 36mm 0.94 (24) S612H3-18L 3-1/8" 2.09 (53)
S612M38 38mm 1.02 (26) S612H3-38L 3-3/8" 2.2 (56)
S612H1-1316 1-13/16" 1.18 (30)
S612H1-78 1-7/8" 1.26 (32) S612M41 41mm 1.1 (28) S612H3-12L 3-1/2" 2.32 (59)
S612M46 46mm 1.18 (30) S612H3-916L 3-9/16" 2.32 (59)
S612H1-1516 1-15/16" 1.26 (32)
S612H2 2" 1.26 (32) S612M50 50mm 1.26 (32) S612H3-34L 3-3/4" 2.4 (61)
S612M54 54mm 1.46 (37) S612H3-78L 3-7/8" 2.56 (65)
S612H2-116 2-1/16" 1.34 (34)
S612M55 55mm 1.46 (37) S612H3-1516L 3-15/16" 2.56 (65)
S612H2-18 2-1/8" 1.46 (37)
S612M58 58mm 1.54 (39) S612H4L 4" 2.56 (65)
S612H2-316 2-3/16" 1.46 (37)
S612H2-14 2-1/4" 1.54 (39) S612M60 60mm 1.54 (39) S612H4-116L 4-1/16" 2.68 (68)
S612M62 62mm 1.65 (42) S612H4-18L 4-1/8" 2.68 (68)
S612H2-516 2-5/16" 1.54 (39)
S612H2-38 2-3/8" 1.54 (39) S612M65 65mm 1.65 (42) S612H4-316L 4-3/16" 2.68 (68)
S612M68 68mm 1.81 (46) S612H4-14L 4-1/4" 2.83 (72)
S612H2-716 2-7/16" 1.65 (42)
S612M70 70mm 1.81 (46) S612H4-516L 4-5/16" 2.83 (72)
S612H2-12 2-1/2" 1.65 (42)
S612H2-916 2-9/16" 1.65 (42) S612M73 73mm 1.93 (49) S612H4-38L 4-3/8" 2.83 (72)
S612M75 75mm 1.93 (49) S612H4-716L 4-7/16" 2.83 (72)
S612H2-58 2-5/8" 1.81 (46)
S612H2-1116 2-11/16" 1.81 (46) S612M78 78mm 2.09 (53) S612H4-12L 4-1/2" 3.03 (77)
S612M80 80mm 2.09 (53) S612H4-58L 4-5/8" 3.03 (77)
S612H2-34 2-3/4" 1.81 (46)
S612H2-1316 2-13/16" 1.93 (49) S612M85 85mm 2.2 (56) S612H4-34L 4-3/4" 3.03 (77)
S612M90 90mm 2.32 (59)
