We Make Connections EZ! Cable Management
Part No. Description Qty
A JH901-100 Vertical Overhang 180º with 1/4" Hole (C Purlin Applications) 100
B JH902-100 Angled Overhang 45º with 1/4" Hole (Z Purlin Applications) 100
C JH910-100 Hammer-On Beam Clamp 1/8" Thru 1/4" with 1/4" Hole 100
D JH911-100 Hammer-On Beam Clamp 5/16" Thru 1/2" with 1/4" Hole 100
E JH915-100 Spring Steel Hammer-On Beam Clamp, for flanges 1/8"-1/4" thick with 1/4"-20 Threaded Impression
on Bottom and Back of Clamp 100
F JH916-100 Spring Steel Hammer-On Beam Clamp, for flanges 5/16"-1/2" thick with 1/4"-20 Threaded Impression
on Bottom and Back of Clamp 100
G JH920-100 Angle Clip 90º - End Hook with 1/4"-20 Thread & 1/4" Hole 100
H JH930-100 Angle Clip 90º - End Hook with 1/4"-20 Thread & Powder Actuated Nail 100
I JH932-100 Angle Clip 90º - Powder Actuated Nail with 1/4" Hole 100
J JH940-100 Eye Lag Screw - 3" Overall Length, 3/16" Hole & 1 1/2" Thread Length (Wood Applications) 100
K JH941-100 Eye Lag Screw - 2" Overall Length I-LAG Brand Eye Lag Screw, 3/16" Hole & 3/4" Thread Length
™
(16-22 Gauge, Sheet Metal Applications) ICC ESR-4272 100
L JH960-100 Multi-Function Clip - Batwing with 1/4"-20 and 10-24 Impressions 100
M JH965-50 Pressed Beam Clamp 1/8" Thru 1/2" Flanges, 1/4"-20 Threads 50
N JH966-100 Spring Steel Beam Clamp for 1/8" Thru 1/2" Flanges with 1/4"-20 & 10-24 Impressions 100
O JH967-100 All Purpose Clip, Hammer-On 1/8" Thru 1/2" Flanges with 1/4"-20 & 10-24 Impressions &
accommodates Drive Rings 100
P JH975 Installation Tool - Vertical (JH901-100) and Angled Overhang (JH902-100) 1
Q JH980 Installation Tool - Eye Lag Driver – Fits Into Any Drill, Hex 1/4" Hex 1
Bridle Rings JH965-50
Support and secure your communication and other low voltage cables with these (Pressed Beam
various sized Bridle Rings. Simple and effective. Constructed of solid low carbon JH966-100 Clamp)
steel. The perfect choice for cable management made easy! (Spring Steel
Beam Clamp)
JH802-100
Part # Qty. Description
JH802-100 100/box 10 x 24 - 3/4" ID JH807-100
JH804-100 100/box 10 x 24 - 2" ID NOTE:
JH807-100 100/box 1/4" x 20 - 1 1/4" ID Hardware sold JH809-50
JH808-100 100/box 1/4" x 20 - 2" ID separately JH967-100
from
JH809-50 50/box 1/4" x 20 - 4" ID Bridle Rings (All Purpose Clip)
JH813-100 100/box 1/4" Wood Screw - 1 1/4" ID
JH814-100 100/box 1/4" Wood Screw - 2" ID
JH814-100
JH804-100 JH807-100 JH813-100
JH809-50
www.platinumtools.com See Page 106 For Warning Information 67
