Cable Management

HPH J-Hooks with Rare Earth Magnets Rare Earth Magnets

Rare Earth Magnets Features
Today, organizing and managing low voltage cables
being used in non-permanent applications is HPH16MH-10BL HPH32MV-10R • Concentrated magnetic force
simple, easy, safe and quick to install. The • Fast installation saves time
secret? Rare Earth Magnets being integrated and money
with both the HPH J-Hooks and Bridle • Removeable and reusable
Rings. A great solution for those low • Easy to install
voltage temporary installations!
• Simple to re-route
• Available in top mount, T
Cable Capacity ceiling, vertical (V)
MADE IN THE
Cat5e Cat6 Cat6A Color Side Mount Top Mount • Available in side mount, MADE IN HE
1" HPH16MH-10 HPH16MV-10 wall, horizontal (H) U S A
USA
Size 16 20 15 10 White 10/ Box 10/ Box • Support category cables:
Cat5e/6/6A/7
1" HPH16MH-10BL HPH16MV-10BL
Size 16 20 15 10 Blue 10/ Box 10/ Box • Support coaxial cables:
CCTV, CATV
1" HPH16MH-10BK HPH16MV-10BK
Size 16 20 15 10 Black 10/ Box 10/ Box
1" HPH16MH-10R HPH16MV-10R Side
Size 16 20 15 10 Red 10/ Box 10/ Box Mount
2" HPH32MH-10 HPH32MV-10
Size 32 90 60 35 White 10/ Box 10/ Box
2" HPH32MH-10BL HPH32MV-10BL
Size 32 90 60 35 Blue 10/ Box 10/ Box
2" HPH32MH-10BK HPH32MV-10BK
Size 32 90 60 35 Black 10/ Box 10/ Box
2" HPH32MH-10R HPH32MV-10R
Size 32 90 60 35 Red 10/ Box 10/ Box

Bridle Rings with Magnets Qty
Top
Bridle Ring, 1 ¼", with top 11/4" Ring 2" Ring Mount
mount magnet, 10/Box JH807M-10
Bridle Ring, 2", with top
mount magnet, 10/Box JH808M-10

Magnets Qty
Rare Earth Magnet in housing with ¼-20
female threads, 10/Box MAG420-10

See Page 107
For Warnings
Concerning
Magnets.
