We Make Connections EZ! Cable Management

Standard
Multi-Purpose Standard

J-Hooks Multi-Purpose
J-Hooks
Cable Capacity
Cat5e Cat6 Standard 90º Standard Batwing Standard Features

3/4” JH12-25 JH12AC-25 JH12W-25 • Traditional style,
Size 12 16 10 25/ Box 25/ Box 25/ Box construction grade
3/4" JH12-100 JH12AC-100 JH12W-100 • Stress free cable support
Size 12 16 10 100 / Box 100 / Box 100 / Box to organize and build a
1 5/16” JH21-25 JH21AC-25 JH21W-25 distribution pathway for
Size 21 50 32 25/ Box 25/ Box 25/ Box various types of cables
• The perfect solution for heavy
1 5/16" JH21-100 JH21AC-100 JH21W-100 duty hanging applications
Size 21 50 32 100 / Box 100 / Box 100 / Box
• Use above suspended
2” JH32-25 JH32AC-25 JH32W-25 ceilings, or below raised
Size 32 80 50 25/ Box 25/ Box 25/ Box floors
2" JH32-100 JH32AC-100 JH32W-100 • Pre-assembled with rivet
Size 32 80 50 100 / Box 100 / Box 100 / Box • All steel construction
4" JH64-25 JH64AC-25 JH64W-25 • UL and CUL listed
Size 64 300 185 25 / Box 25 / Box 25 / Box • Material: Galvanized Steel
• Finish: Yellow Zinc Chromate

Standard J-Hook Standard Size Load (lbs.) Standard Size Load (lbs.)
Load Capacity: 12 (3/4") 12 32 (2") 17
21 (1 5/16") 17 64 (4") 50

Beam Spring Steel
Clamp, Beam Clamp,
Cable Capacity Hammer-On, Swivels Swivels
Cat5e Cat6 Swivels 360º Hammer-On 360º 360º
3/4" JH12ACFM24-100 JH12HOK24-100 JH12BC-100 (Beam Clamp)
Size 12 16 10 for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/2", 100/Box
3/4" JH12ACFM58-100 JH12HOK58-100 JH12ACSSBC-100 (Spring Steel Beam Clamp)
Size 12 16 10 for flanges 5/16"-1/2", 100/Box for flanges 5/16"-1/2", 100/Box for flanges 1/8"-1/2", 100/Box

1 5/16" JH21ACFM24-100 JH21HOK24-100 JH21BC-100 (Beam Clamp)
Size 21 50 32 for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/2", 100/Box
1 5/16" JH21ACFM58-100 JH21HOK58-100 JH21ACSSBC-100 (Spring Steel Beam Clamp)
Size 21 50 32 for flanges 5/16"-1/2", 100/Box for flanges 5/16"-1/2", 100/Box for flanges 1/8"-1/2", 100/Box
2" JH32ACFM24-100 JH32HOK24-100 JH32BC-100 (Beam Clamp)
Size 32 80 50 for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/4", 100/Box for flanges 1/8"-1/2", 100/Box
2" JH32ACFM58-100 JH32HOK58-100 JH32ACSSBC-100 (Spring Steel Beam Clamp)
Size 32 80 50 for flanges 5/16"-1/2", 100/Box for flanges 5/16"-1/2", 100/Box for flanges 1/8"-1/2", 100/Box
4" JH64ACFM24-25 JH64HOK24-25 JH64BC-25 (Beam Clamp)
Size 64 300 185 for flanges 1/8"-1/4", 25/Box for flanges 1/8"-1/4", 25/Box for flanges 1/8"-1/2", 25/Box
4" JH64ACFM58-25 for JH64HOK58-25 JH64ACSSBC-25 (Spring Steel Beam Clamp)
Size 64 300 185 for flanges 5/16"-1/2", 25/Box for flanges 5/16"-1/2", 25/Box for flanges 1/8"-1/2", 25/Box

www.platinumtools.com See Page 106 For Warning Information 65
