P. 42
Connectors
SealSmart Coax Compression “F” Connectors Cable/Connector
™
Color Code
Red RG59
Black RG6
RG6Q Blue RG6Q
Right Angle Navy Mini
Packaging Description Gold Plated Nickel Plated Nickel Plated
Bag – 100 Pieces 18004 18001
Bag – 25 Pieces 18001RA
Jar – 75 Pieces 28001J
Clamshell – 10 Pieces 18005 18002 SealSmart II
Clamshell – 3 Pieces 18003 Compression Crimp Tool
RG6 Easily terminate F, RCA, and BNC compression
style connectors without changing adapters.
Right Angle
Packaging Description Gold Plated Nickel Plated Nickel Plated
Bag – 100 Pieces 18009 18006
Bag – 25 Pieces 18006RA
Jar – 75 Pieces 28006J
Clamshell – 10 Pieces 18010 18007
Clamshell – 3 Pieces 18008 16220C
RG59
Right Angle
Packaging Description Gold Plated Nickel Plated Nickel Plated
Bag – 100 Pieces 18015 18011
Bag – 25 Pieces 18011RA
Jar – 75 Pieces 28011J See pages 22 & 23
Clamshell – 10 Pieces 18016 18012 for additional compression crimp tools
Clamshell – 3 Pieces 18013
RGB 25 AWG RGB 23 AWG
Packaging Description Gold Plated Nickel Plated Packaging Description Gold Plated Nickel Plated
Bag – 25 Pieces 18225 18220 Bag – 25 Pieces 18215 18210
RG11
RGB 24 AWG
Packaging Description Nickel Plated
Packaging Description Gold Plated Nickel Plated Bag – 25 Pieces 18311
Bag – 25 Pieces 18205 18200 Clamshell – 4 Pieces 18312
40 See Page 106 For Warning Information Phone: 800.749.5783 Fax: 800.749.5784
