Specialty Tools
We Make Connections EZ!

1KV Insulated Slotted Terminal Block Screwdriver
Insulated precision 3mm flathead screwdriver with full-size handle for electrical screw terminal barrier
blocks. Provides shock protection to 1000 VAC and complies with VDE safety standard VDE-400009250.

Features
• 3mm black oxide slot-head tip Bit
Included
• Dual-compound insulated handle
• Red shaft insulation for easy visibility
• Provides shock protection to 1000VAC
• Complies with VDE safety standard
VDE-400009250

Part # Description
19202C 1KV Insulated Slotted Terminal Block Screwdriver

1 KV Insulated Precision, 6 Piece Screwdriver Set
Convenient set of insulated, precision slotted, and Phillips screwdrivers in a plastic
storage/carrying case. The screwdrivers provide shock protection to 1000 VAC
and complies with VDE safety standard VDE-400009250.

Features
• Black oxide tip
Bits
• Dual-compound handle Included

19110 Bit Load
• Includes the following sizes:
– Slotted: 0.23 x 1.5 x 65 /
0.4 x 2.0 x 65 / 0.4 x 2.5 x 65
– Phillips: PH00 x 65 /
PH0 x 65 / PH1 x 65

Part # Description
19110 1 KV Insulated Precision, 6 Piece Screwdriver Set

Reshaping the BIG Stuff Before

Having trouble inserting cable into your connector?
Use the grip cavity of your pliers and lightly compress the concentricity After
Tips & of your cable, re-shaping it into an oval/rectangular shape. This will make
Tricks it much easier to insert the cable into the back end of the connector and
push it to the correct location as required by termination specs.
Remember, the distance from the point of termination to the twists are:
• Cat5e = less than 1/2” • Cat6 = less than 3/16”
NOTE: This deformation will not interfere with passing certification.

www.platinumtools.com See Page 106 For Warning Information 39
