Torque Wrench ER Series - Electronic with Storage

Reversible Ratchet Head Torque Wrench English
ERM Model
Both directions, 8° swing suitable for confined space Shank Size Torque Range Increment Length Width Weight
Item No.
ER Model (English Unit) mm Lb.ft N.m Lb.ft mm mm kg
ERH9200 9×12 20-200* 2.3-22.6 0.1* 377 24 0.77
ERH9250 9×12 25-250* 2.8-28.2 0.1* 377 24 0.77
ERH9450 9×12 45-450* 5.1-50.8 0.1* 417 24 0.85
ERH9100 9×12 10-100 13.5-135 0.1 447 24 0.92
Matching
Sockets ERH14150 14×18 15-150 20.3-203 0.1 493 32 1.05
ERH14250 14×18 25-250 34.0-340 0.1 561 32 1.22
Metric
*Unit is Lb.in
Square Torque Range Increment Length Width Weight
Item No.
Drive N.m Lb.ft N.m mm mm kg
ERM120 1/4" 2-20 17.7-177* 0.01 393 28 0.8
ERM230 3/8" 3-30 26.6-266* 0.01 405 38 0.83 Teardrop Ratchet Head Torque Wrench
ERM250 3/8" 5-50 44.3-443* 0.01 445 38 0.92 ERMBQL Model Both directions, easily operated reverse lever
ERM2100 3/8" 10-100 7.4-73.8 0.1 475 38 0.98
ERM3200 1/2" 20-200 14.8-148 0.1 515 40 1.1 ERBQL Model (English Unit)
ERM3300 1/2" 30-300 22.1-221 0.1 583 40 1.25
ERM4400 3/4" 40-400 29.5-295 0.1 800 57 3.3
ERM4600 3/4" 60-600 44.3-443 0.1 1050 60 4.6
ERM4800 3/4" 80-800 59.0-590 0.1 1250 60 5.2 Matching
ERM41000 3/4" 100-1000 73.8-738 0.1 1250 60 5.2 Sockets
ERM51500 1" 150-1500 110-1100 1 1265 75 6.1 Metric
ERM52000 1" 200-2000 150-1500 1 1600 75 6.5 Square Torque Range Increment Length Width Weight
Item No.
*Unit is Lb.in Drive N.m Lb.ft N.m mm mm kg
English ERMBQL120 1/4" 2-20 17.7-177* 0.01 401 25 0.87
Square Torque Range Increment Length Width Weight ERMBQL230 3/8" 3-30 26.6-266* 0.01 407 33 0.89
Item No.
Drive Lb.ft N.m Lb.ft mm mm kg ERMBQL250 3/8" 5-50 44.3-443* 0.01 447 33 0.99
ER1200 1/4" 20-200* 2.3-22.6 0.1* 393 28 0.8 ERMBQL2100 3/8" 10-100 7.4-73.8 0.1 477 33 1.05
ER2250 3/8" 25-250* 2.8-28.2 0.1* 405 38 0.83 ERMBQL3200 1/2" 20-200 14.8-148 0.1 529 40.5 1.15
ER2450 3/8" 45-450* 5.1-50.8 0.1* 445 38 0.92 ERMBQL3300 1/2" 30-300 22.1-221 0.1 597 40.5 1.26
ER2100 3/8" 10-100 13.5-135 0.1 475 38 0.98 ERMBQL4400 3/4" 40-400 29.5-295 0.1 800 64 3.3
ER3150 1/2" 15-150 20.3-203 0.1 515 40 1.1 ERMBQL4600 3/4" 60-600 44.3-443 0.1 1050 64 4.6
ER3250 1/2" 25-250 34.0-340 0.1 583 40 1.25 ERMBQL4800 3/4" 80-800 59.0-590 0.1 1250 64 5.2
*Unit is Lb.in ERMBQL41000 3/4" 100-1000 73.8-738 0.1 1250 64 5.2
*Unit is Lb.in
Rectangular Shank Head Holder Torque Wrench English
ERMH Model Square Torque Range Increment Length Width Weight
For rectangular shank head inserts Item No.
Drive Lb.ft N.m Lb.ft mm mm kg
ERH Model (English Unit) ERBQL1200 1/4" 20-200* 2.3-22.6 0.1* 401 25 0.87
ERBQL2250 3/8" 25-250* 2.8-28.2 0.1* 407 33 0.89
ERBQL2450 3/8" 45-450* 5.1-50.8 0.1* 447 33 0.99
ERBQL2100 3/8" 10-100 13.5-135 0.1 477 33 1.05
Optional ERBQL3150 1/2" 15-150 20.3-203 0.1 529 40.5 1.15
Fittings: ERBQL3250 1/2" 25-250 34.0-340 0.1 597 40.5 1.26
Metric *Unit is Lb.in
Shank Size Torque Range Increment Length Width Weight
Item No.
mm N.m Lb.ft N.m mm mm kg
ERMH920 9×12 2-20 17.7-177* 0.01 377 24 0.77
ERMH930 9×12 3-30 26.6-266* 0.01 377 24 0.77
ERMH950 9×12 5-50 44.3-443* 0.01 417 24 0.85 100%
ERMH9100 9×12 10-100 7.4-73.8 0.1 447 24 0.92
ERMH14200 14×18 20-200 14.8-148 0.1 493 32 1.05 Calibrated PF339100
ERMH14300 14×18 30-300 22.1-221 0.1 561 32 1.22 Unique serial number for
ERMH14400 14×18 40-400 29.5-295 0.1 780 32 3 each torque wrench,
ERMH24600 24×32 60-600 44.3-443 0.1 1050 56 4.5 corresponding to the
ERMH24800 24×32 80-800 59.0-590 0.1 1250 56 5 certificate of calibration
ERMH241000 24×32 100-1000 73.8-738 0.1 1250 56 5.1
*Unit is Lb.in

12
