Insulation Strippers

universal

> For single, multiple and fine stranded conductors with plastic or rubber
insulation up to Ø 5.0 mm or 10 mm²
> Easy adjustment to the required diameter of stranded wire with knurled 11 06 160
screw and lock nut
> Easy adjustment to the required diameter of solid or stranded wire with
knurled screw and lock nut
> Special tool steel, forged, oil-hardened
> DIN EN 60900, IEC 60900
11 06 160 T
> Pliers with integrated insulated tether attachment
point for a tool tether
11 07 160

EAN Stripping capacities
Article No. 4003773- mm Pliers Head Handles Ø mm mm² AWG g
11 06 160 021933 160 chrome-plated chrome-plated insulated with multi-component grips, VDE-tested 5.0 10 8 180
insulated with multi-component grips with integrated
11 06 160 T 081418 160 chrome-plated chrome-plated insulated tether attachment point, VDE tested 5.0 10 8 180
11 07 160 015499 160 chrome-plated chrome-plated with dipped insulation, VDE-tested 5.0 10 8 205
11 09 01 052326 Set of spare parts (screw and nut) for 11 160

®
KNIPEX StriX

Insulation strippers with cable shears

► Wire stripper with cable shears – two essential
electrical installation tools in one pair of pliers 13 66 180

> Integrated cable shears for the clean cutting of Cu- and Al-cables
without crushing up to Ø 15 mm (5 x 2,5 mm²)
> Cutting edges additionally induction-hardened, cutting edge hardness
approx. 57 HRC
> Universal adjustment of the stripping blades by means of a knurled
screw
> Slim dimensions for easy access
> Stripping of single-, multi- and fine stranded conductors with plastic 13 66 180 T
or rubber insulation up to Ø 5 mm or 10 mm² cross-section
> Graduated jaw provides a visual orientation aid when stripping wire
in standard lengths (11 mm and 16 mm)
> High-grade special tool steel, forged, multi stage oil-hardened
> DIN EN 60900, IEC 60900

13 66 180 T*
> Pliers with integrated insulated tether attachment
point for a tool tether

EAN Stripping capacities
Article No. 4003773- mm Pliers Handles Ø mm mm² AWG g
13 66 180 081319 180 chrome-plated insulated with multi-component grips, VDE-tested 5.0 10 8 213
insulated with multi-component grips with integrated
13 66 180 T 081906 180 chrome-plated insulated tether attachment point, VDE tested 5.0 10 8 216

11 09 01 052326 Set of spare parts (screw and nut) for 11 XX 160

INSULATED TOOLS I 219
