CABLE TERMINATION

Strippers, Cutters, and Crimpers Compact Pass-Thru™ Modular Crimper TM

•
Crimps and trims STP/UTP paired-conductor data cables with Klein Tools RJ45 Pass-Thru connectors
•
Trims flush to end face of connector to eliminate unintended contact between conductors
•
• On-tool wiring guide helps minimize wiring errors REPLACEMENT
Fast, reliable RJ45 Pass-Thru™ modular crimp-connector installation for data applications
•
Drivers and Wrenches • Not for use with standard (non Pass-Thru™) connectors BLADE KIT VDV226-005
Use with Klein Tools Pass-Thru™ connectors
VDV999-078
•
Replacement blades available (Cat. No. VDV999-078)
Cat. No. Cuts & Strips Cable Size Connector Type Position/Pair/Conductors Overall Length
RJ45 Klein Tools Pass-Thru™
5.5" (14 cm)
CAT5e, CAT6
VDV226-005
–
8-Position, 4-Pair/8-Conductor
Conduit Tools and Measurement Ratcheting Modular Crimper/Stripper
• Fast, reliable modular-crimp connector installation for voice and data applications
• All-In-One Tool, cuts, strips and crimps paired-conductor cables (round STP/UTP and flat-satin phone cable)
Tool Kits • Crimps 4, 6, and 8 position modular connectors (RJ22, RJ11/RJ12, and RJ45)
•
Steel body with black-oxide finish for excellent performance and durability
• Crimping dies are precision ground from high-carbon steel
• Designed for Western Electric (WE)/Stewart Stamping (SS)-type modular connectors REPLACEMENT VDV226-011-SEN
• Ratchet safety-release and a blade-guard on cutting and stripping knives reduce risk of injury BLADE KIT
•
VDV999-064
Safety, PPE and Comfort
Full-cycle ratchet mechanism prevents the release of the connector prior to full compression
Cat. No.
VDV226-011-SEN Cuts & Strips Cable Size Connector Type Position/Pair/Conductors Overall Length
4-Position, 1-Pair/2-Conductor, 4-Position,
7.5" (19.1 cm)
RJ45, RJ11, RJ12 Standard
STP/UTP Paired-Conductor
CAT3, CAT5e,
Data Cable CAT6/6A 2-Pair/4-Conductor 6-Position, 2-Pair/4-Conduc-
tor, 6-Position, 3-Pair/6-Conductor, 8-Position,
4-Pair/8-Conductor
Jobsite Accessories Compact Ratcheting Modular Crimper
• All-in-one tool cuts and strips STP/UTP paired-conductor data
cable and flat-satin voice cable
•
Tool Storage • Full-cycle ratchet mechanism ensures complete connector termination
Crimps with RJ11/12 and RJ45 modular connectors
•
Direct lateral crimp action provides more even, precise contact
BLADE KIT
• termination across all pins REPLACEMENT VDV226-107
Compact, ergonomic design for natural, single-hand operation
VDV999-074
•
On-tool working guide helps minimize wiring errors
Voice/Data/Video • Replacement blades available (Cat. No. VDV999-074) Cable Size Connector Type Position/Pair/Conductors Overall Length
Cuts & Strips
Cat. No.
RJ11
CAT3, CAT5e, CAT6
6-Position, 2 Pair/4-Conductor;
5.25" (13.3 cm)
VDV226-107
STP/UTP Paired-Conductor Data Cable
RJ12 and RJ45 Standard
Flat-Satin Phone Cable
6-Position, 3-Pair/6-Conductor;
8-Position, 4-Pair/8-Conductor
Test and Measurement Ratcheting Crimper Frame
• Professional CATV, electrical, home theater, satellite and security system ratcheting crimper
frame with optional dies is perfect for fast, reliable connector installations
• Full-cycle ratchet action assures a complete, precise crimp every cycle
• Preset tension for optimum performance
• Ratchet mechanism is designed to prevent the release of the connector prior to full compression
Power Tools and Accessories • Safety crimp release helps eliminate rejected terminations due to incorrect positioning VDV200-010
•
Steel body with black-oxide finish for corrosion resistance and durability
•
Thumb-screws secure die-sets for quick, easy changes
•
Optional, quick interchangeable die sets thumb and Phillips screw set available (see table)
NOTE: Use caution when tightening thumb screws to prevent thread
Cat. No. Handle Color Overall Length damage/stripping and hand tighten only; do not over-tighten the thumb
screws. Over-tightening thumb-screws can damage the tool and/or die set.
Lifting, Pulling, and Structural 228 www.kleintools.com > 800-553-4676
VDV200-010
Black/Yellow
8.75" (22.2 cm)
