LEVELS Pliers

Self-Leveling Cross-Line Laser Level with Red Plumb Spot
Includes core Laser Level features plus: and Crimpers Strippers, Cutters,
• High-performance laser leveling and alignment tool for professionals that provides
a reliable self-leveling pendulum
• Horizontal and vertical laser lines and red plumb spot lasers that project horizontal
and vertical lines independently or together to address various alignment tasks
• Integrated magnetic 360° mounting bracket with 1/4" and 5/8"
(0.6 cm and 1.6 cm) tripod mounting threads Wrenches Drivers and
• Low battery indicator and easily accessible battery compartment
• High capacity rechargeable Li-ion battery powers all lasers
with more than 15 hours of run time (Cat. No. 93LCLGR)

S
R and Measurement Conduit Tools

Cat. No. Laser Color Accuracy Overall Height Overall Width Overall Length
(
(
p
p
)
p
)
p
93LCLGR Cross-Line: Green; ±3/32"per 33' (±2 mm per 10 m) Vertical & Horizontal Beams, ±1/8" per 33' (±3 mm per 10 m) Plumb 5.3" (13.5 cm) 2.6" (6.6 cm) 5.2" (13.2 cm) Tool Kits
Plumb: Red Up Spot, ±5/32" per 33' (±4 mm per 10 m) Plumb Down Spot
)
)
p
(
(
p
p
p
93LCLS Cross-Line: Red; ±3/32" per 33' (±2 mm per 10 m) Vertical & Horizontal Beams, ±1/8" per 33' (±3 mm per 10 m) Plumb 5" (12.7 cm) 2.6" (6.6 cm) 5.3" (13.5 cm)
Plumb: Red Up Spot, ±5/32” per 33' (±4 mm per 10 m) Plumb Down Spot
Mini Cross-Line Laser Levels and Comfort Safety, PPE
• Self-Leveling Red Laser Level has an easy-to-read bright red horizontal and
vertical line with a working range of 35' (10.7 m) (Cat. No. 93MCLS)
• Over 18 hours of runtime provides enough laser power to ensure extended all day use (Cat. No. 93MCLS)
• Self-Leveling Green Laser Level has an easy-to-read bright red horizontal and
vertical line with a working range of 50' (15.2 m) (Cat. No. 93MCLG)
• Over 8 hours of runtime provides enough laser power to ensure extended all day use (Cat. No. 93MCLG) Accessories Jobsite
• Projects horizontal and vertical lines to address various alignment tasks
• Compact and lightweight design is easy to use in tight areas and to store when not in use
• High precision laser project clean lines with accuracy of 3/16" at 33' (10 m);
auto out-of-level detection flashes lasers when no longer level
• Magnetic mounting bracket screws into integrated 1/4" (0.6 cm) tripod mount
• Durable overmold design that is IP54 rated protects the laser level from water and dust Tool Storage
Cat. No. Laser Color Accuracy Overall Height Overall Width Overall Length
93MCLG Cross-line, Green +/- 3/16" per 33' (10 m) 4" (10.2 cm) 4.2" (10.7 cm) 3.2" (8.1 cm) Voice/Data/Video
93MCLS Cross-line, Red +/- 3/16" per 33' (10 m) 4" (10.2 cm) 4.2" (10.7 cm) 3.2" (8.1 cm)

Red Pocket Laser Level
• Projects single red laser line up to 30' (9.1 m) indoors, providing ample coverage for a wide range of applications Measurement Test and
• Laser body has a 360° rotation for projecting lines at any angle
• Horizontal and vertical fine adjust knobs allow for easier precision adjustment of the laser line without having to move the unit
• Compact design is easy to use and transport at home, on the job, or anywhere in between
• 3-axis bubble vials illuminate for enhanced viewing and leveling
• Two powerful magnets, 1/4-20 thread tripod mounting, a hang hole, and built-in kickstand give a variety of mounting options and Accessories Power Tools
• Over 12-Hour runtime with 2 AAA alkaline batteries and low battery warning

Cat. No. Laser Color Accuracy Overall Height Overall Width Overall Length
93PTL Red Laser Vials; 0.043° (0.75mm/1,000mm) 2.3" (5.8 cm) 1.76" (4.5 cm) 4.27" (10.8 cm)
