Hand tools

Measurement

2154 Precision vernier calliper 2155 Dial gauge

Made in Germany K C KR
• Measuring range: up to 150 mm
• Depth gauge
• mm and inch increments
1
• Vernier 0.05 mm and ⁄128″ 1 4
• Fixing screw
• In pocket Magnetic dial gauge stand
• Made of stainless steel • Magnetic base with prism support (e.g. for shafts)
• DIN 862 • On/Off switch for magnetic force
• Dial gauge holder for 4.5 mm and 8 mm shaft
• Horizontal rod for fine adjustment and articulation
2155-60 144303

1 K 4 Mechanical dial gauge
• Scale graduation: 0.01 mm
2154-10 234 013142 • Measuring range: 8 mm
• 1 needle rotation: 1 mm
• Rotary and lockable scale
2154 Vernier calliper ∙ digital • Target area can be limited by two needles
• Clamping shaft: x 8 mm
• Measuring range: up to 150 mm K • Dial gauge x 40 mm
• Depth gauge 2155-65 144501
• Reversible from mm to inch
• With interface RS 232 C
for data processing 2145 Precision knife-edge straightedge
• On/off switch
• Including battery Made in Germany K
• Made of stainless steel • Measuring edge hardened
• Plastic box
• DIN 862 • Application: Inspecting the evenness (flatness) of surfaces, e.g. cylinder head
• Ground and lapped
• Antirust
• Non-glaring
• Insulating handle
• In artificial leather case
• DIN 874-2

1 K 4
2154 N-20 234 127696

2155 N Precision micrometer 1 K 4
2145-500 500 073146
• Clamp ring and ratchet stop KR
• Spindle hidden inside, ground and hardened, adjustable
• Insulating plates 2147 Feeler gauge
• Carbide tipped measuring surface
• Pitch: 0.5 mm IKJR
reading: 0.01 mm
• Wooden box
• DIN 863-3
• Measuring range 0 – 25 mm

1 4
2155 N-25 127702

2155 Dial gauge

KR 1 K mm 4
• mm dimensions = feeler gauge set D
• 20 pieces, increasing by 0.05–1.0 mm
• Stainless steel
• Length of blades (bore hole – tip): 69.73 mm
• Radius on the tip 15 mm
• Checking the electrode distance in spark plugs
2147 106 0.05 – 1.0 012824
• Brass – non-magnetic –
• Setting e.g. sensors on ABS
• Checking the electrode distance of platinum spark plugs
• 20 pieces, increasing by 0.05–1.0 mm
2155-65 • Checking the electrode distance in spark plugs
B 2147 MS 106 0.05 – 1.0 057603

Components and spare parts from page 500 to 509 Errors excepted 269
